P. 568

                    LIGHTING
Battens
Colour Switchable LED Battens With Push Clip Release
  batpaccs bat pac cs
• Updated design with a push clip release mechanism at each end
• Hinged gear tray for fast installation
• Delivering up to 127lm/W
• Opal polycarbonate diffuser
• IK08 rated impact resistance
• Knockouts for cable entry on
both ends
Single Colour Switchable
Twin Colour Switchable
• Push-fit terminals
• Multiple BESA mounting points
(matches traditional fluorescent)
• Adjustable light detector from 2-50
lux for microwave option
• Adjustable hold time of 5 seconds
to 30 minutes for microwave
option
• Can be surface mounted or
suspended
   Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-BA1222CCT*
 Non-Dim
 20W
 3000-6300K
 2600lm
 130
 1 x 36W
 4
 EN-BA1533CCT*
  Non-Dim
  30W
  3000-6300K
  3900lm
  130
  1 x 58W
  5
 EN-BA1839CCT*
 Non-Dim
 40W
 3000-6300K
 5200lm
 130
 1 x 72W
 6
    Quick Release Hinged Gear Tray for Faster Installation
Switch between WW-3000K (Warm White) NW-4000K  (Neutral White) CW-6300K  (Cool White)
works with .control
On/Off Relay
    Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-BA1243CCT*
 Non-Dim
 40W
 3000-6300K
 5200lm
 130
 1 x 36W
 4
 EN-BA1563CCT*
  Non-Dim
  60W
  3000-6300K
  7800lm
  130
  1 x 58W
  5
 EN-BA1873CCT*
 Non-Dim
 65W
 3000-6300K
 8400lm
 130
 1 x 72W
 6
     *Add suffix EM for Emergency options.
Lumen value based on 4000K
Colour switchable between 3000K, 4000K and 6300K (switch in gear tray) 5 Year Warranty
EN-BA1222CCT
(L) 1170 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1839CCT
(L) 1734 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1563CCT
(L) 1470 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1533CCT
(L) 1470 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1243CCT
(L) 1170 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1873CCT
 W
HL
(L) 1734 mm Length (W) 61mm Width (H) 71 mm Height
 LED Battens With Push Clip Release
batpac bat pac
Single
Twin
works with .control
HL
EN-BA1222
(L) 1170 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1533
(L) 1470 mm Length (W) 61mm Width (H) 71 mm Height
On/Off Relay
EN-BA1839
(L) 1734 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1243
(L) 1170 mm Length (W) 61mm Width (H) 71 mm Height
GENERATE VALUE
   Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-BA1222*/30
 Non-Dim
 22W
 3000K
 2400lm
 109
 1 x 36W
 4
 EN-BA1222*/40
 Non-Dim
 22W
 4000K
 2800lm
 127
 1 x 36W
 4
 EN-BA1533*/30
  Non-Dim
  33W
  3000K
  3600lm
  109
  1 x 58W
  5
 EN-BA1533*/40
Non-Dim
33W
4000K
4100lm
124
1 x 58W
5
 EN-BA1839*/30
  Non-Dim
  39W
  3000K
  4300lm
  110
  1 x 72W
  6
 EN-BA1839*/40
 Non-Dim
 39W
 4000K
 4900lm
 126
 1 x 72W
 6
       Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-BA1243*/30
 Non-Dim
 43W
 3000K
 4800lm
 112
 1 x 36W
 4
 EN-BA1243*/40
 Non-Dim
 43W
 4000K
 5300lm
 123
 1 x 36W
 4
 EN-BA1563*/30
 Non-Dim
 63W
 3000K
 7000lm
 111
 1 x 58W
 5
 EN-BA1563*/40
 Non-Dim
 63W
 4000K
 7800lm
 124
 1 x 58W
 5
 EN-BA1873*/30
  Non-Dim
  73W
  3000K
  8000lm
  110
  1 x 72W
  6
 EN-BA1873*/40
 Non-Dim
 73W
 4000K
 9100lm
 125
 1 x 72W
 6
       W
  *Add suffix EM or MS for Emergency or Microwave Sensor options. 5 Year Warranty
EN-BA1563
(L) 1470 mm Length (W) 61mm Width (H) 71 mm Height
EN-BA1873
(L) 1734 mm Length (W) 61mm Width (H) 71 mm Height
 Conservation of Fuel and Power
compliant
 Conservation of Fuel and Power
compliant
