P. 571

                    LIGHTING
Bulkheads
IP66 Round/Eyelid LED Bulkheads
   orbital
• Polycarbonate body and diffuser
• Rear entry access wiring
compartment allows for easy
installation
• Separate 20mm conduit side
entry
• Delivering up to 80lm/W
• IP66 rated
Non-Dimmable
Accessories
• IK10 rated impact resistance
• Adjustable hold time 5 seconds to 10 minutes for microwave option
• Adjustable light detector for microwave option
• For ambient temperatures from -25oC to 40oC
works with .control
    On/Off Relay
P
EN-BH15
OD
Part No. Watts Colour Lumens lm/W
  EN-BH15*/40†
  15W
  4000K
  1150lm
  77
 EN-BH15*/40EM
17W
4000K
1150lm
68
 EN-BH25*/40†
 25W
 4000K
 1800lm
 72
 EN-BH25*/40EM
  27W
  4000K
  1800lm
  67
 EN-BH35*/40†
 35W
 4000K
 2800lm
 80
 EN-BH35*/40EM
 37W
 4000K
 2800lm
 76
        Part No. Description
  EN-BZE15W
 OrbitalTM 300mm Eyelid Bezel Accessory for EN-BH15 - White
 EN-BZE15BLK
 OrbitalTM 300mm Eyelid Bezel Accessory for EN-BH15 - Black
 EN-BZE25W
  OrbitalTM 360mm Eyelid Bezel Accessory for EN-BH25 - White
 EN-BZE25BLK
OrbitalTM 360mm Eyelid Bezel Accessory for EN-BH25 - Black
 EN-BZE35W
  OrbitalTM 420mm Eyelid Bezel Accessory for EN-BH35 - White
 EN-BZE35BLK
 OrbitalTM 420mm Eyelid Bezel Accessory for EN-BH35 - Black
  *Add suffix W or BLK for White or Black finishes
†Add suffix MS for Microwave Sensor
EN-BH25 27W EMMS (Emergency & Microwave Sensor) available to special order 3 Year Warranty
IP65 Utility LED Bulkheads
(OD) 300mm Overall   (P) 95mm Projection
EN-BH25
(OD) 360mm Overall   (P) 105mm Projection
EN-BH35
(OD) 420mm Overall   (P) 112mm Projection
    utilite
• Polycarbonate housing
• Delivering up to 103lm/W
• IP65 rated
• IK06 rated impact resistance
Non-Dimmable
3 Year Warranty
• Integrated driver for slim profile
• Bezels do not sit flush to the wall
works with .control
On/Off Relay
   Part No. Watts Colour Lumens lm/W Shape
  EN-BH104/40
 4W
 4000K
 425lm
 106
 Round
 EN-BH108/40
  8W
  4000K
  850lm
  106
  Round
 EN-BH115/40
15W
4000K
1550lm
103
Round
 EN-BH120/40
 20W
 4000K
 2000lm
 100
 Round
 EN-BH130/40
 30W
 4000K
 2800lm
 93
 Round
 EN-BH215/40
  15W
  4000K
  1550lm
  103
  Oval
 EN-BH220/40
 20W
 4000K
 1800lm
 90
 Oval
         P
Black Bezel
Black Bezel
Eyelid
Grille
Grille
P
 Conservation of Fuel and Power
compliant
 Conservation of Fuel and Power
compliant
   Together we
571
EN-BH104
EN-BH108
EN-BH115
EN-BH120
EN-BH130
L
EN-BH215
(L) 215mm Length (W) 115mm Width (P) 62mm Projection
EN-BH220
(L) 271mm Length (W) 146mm Width (P) 76mm Projection
OD (OD) 167mm Overall   (OD) 167mm Overall   (OD) 167mm Overall   (OD) 221mm Overall   (OD) 300mm Overall   (P) 62mm Projection (P) 62mm Projection (P) 62mm Projection (P) 72mm Projection (P) 80mm Projection
