                    LIGHTING
Amenity Lighting
Sloane 2.0
A spherical luminaire with an effective light distribution, Sloane 2.0 is ideal for large area amenity applications
• 35W - 55W
• 2,548 - 4,005 Luminaire Lumens
• Efficacy up to 73 Im/W
• 4000K, CRI >70
• Lifetime >50,000hr, L70
       Part No. Description Wattage Luminaire Lumens Dimensions
  SLOA35F
 Symmetrical LED Post Top IP65 IK10
 35W
 2548lm
 520x520x520mm
 SLOA35FPEC
  Symmetrical LED Post Top IP65 IK10
  35W
  2548lm
  520x520x520mm
 SLOA55F
 Symmetrical LED Post Top IP65 IK10
 55W
 4005lm
 520x520x520mm
 SLOA55FPEC
 Symmetrical LED Post Top IP65 IK10
 55W
 4005lm
 520x520x520mm
   Civica 2.0
This classic amenity luminaire is made from robust die-cast aluminium and is perfect for a wide range of applications.
• 40W - 60W
• 4,400 - 6,700 Luminaire Lumens
• Efficacy up to 112 Im/W
• 4000K, CRI >70
• Lifetime >100,000hr, L70
       Part No. Description Wattage Luminaire Lumens Dimensions
  CIV40F
 4000K IP65 IK08 c/w Driver
 40W
 4400lm
 600x600x426mm
 CIV40FPEC
 4000K IP65 IK08 c/w Driver & Pcell
 40W
 4400lm
 600x600x426mm
 CIV60F
  4000K IP65 IK08 c/w Driver
  60W
  6700lm
  600x600x426mm
 CIV60FPEC
 4000K IP65 IK08 c/w Driver & Pcell
 60W
 6700lm
 600x600x426mm
