                    LIGHTING
Bulkheads
Quarto 2.0
A stylish, modern bulkhead available with LED emergency and photocell. Quarto 2.0 is suited to building and perimeter lighting.
• 7W - 14W
• 806 - 1,542 Luminaire Lumens
• Efficacy up to 114 Im/W
• 4000K, CRI >70
• Lifetime >100,000hr, L80
        Part No. Description Wattage Luminaire Lumens Dimensions
  QUAFL08D
  4000K IP65 IK10
  7.5W
  857lm
  231x230x230mm
 QUAFL08DEM
3 Hour Flat Glass 4000K IP65 IK10
7.5W
857lm
231x230x230mm
 QUAFL08DEMPEC
 3 Hour Flat Glass 4000K IP65 IK10
 7.5W
 857lm
 231x230x230mm
 QUAFL08DPEC
 Flat Glass 4000K IP65 IK10
 7.5W
 857lm
 231x230x230mm
 QUAFL15D
  4000K IP65 IK10
  14.2W
  1542lm
  231x230x230mm
 QUAFL15DEM
3 Hour Flat Glass 4000K IP65 IK10
14.2W
1542lm
231x230x230mm
 QUAFL15DEMPEC
 3 Hour Flat Glass 4000K IP65 IK10
 14.2W
 1542lm
 231x230x230mm
 QUAFL15DPEC
 Flat Glass 4000K IP65 IK10
 14.2W
 1542lm
 231x230x230mm
 QUAOC08D
 4000K IP65 IK10
 7.5W
 825lm
 231x230x230mm
 QUAOC08DEM
  3 Hour Flat Glass 4000K IP65 IK10
  7.5W
  825lm
  231x230x230mm
 QUAOC08DEMPEC
3 Hour Flat Glass 4000K IP65 IK10
7.5W
825lm
231x230x230mm
 QUAOC08DPEC
 Flat Glass 4000K IP65 IK10
 7.5W
 825lm
 231x230x230mm
 QUAOC15D
 4000K IP65 IK10
 14.2W
 1485lm
 231x230x230mm
 QUAOC15DEM
  3 Hour Flat Glass 4000K IP65 IK10
  14.2W
  1485lm
  231x230x230mm
 QUAOC15DEMPEC
3 Hour Flat Glass 4000K IP65 IK10
14.2W
1485lm
231x230x230mm
 QUAOC15DPEC
 Flat Glass 4000K IP65 IK10
 14.2W
 1485lm
 231x230x230mm
 QUAST08D
 4000K IP65 IK10
 7.5W
 806lm
 231x230x230mm
 QUAST08DEM
 3 Hour Flat Glass 4000K IP65 IK10
 7.5W
 806lm
 231x230x230mm
 QUAST08DEMPEC
  3 Hour Flat Glass 4000K IP65 IK10
  7.5W
  806lm
  231x230x230mm
 QUAST08DPEC
Flat Glass 4000K IP65 IK10
7.5W
806lm
231x230x230mm
 QUAST15D
 4000K IP65 IK10
 14.2W
 1453lm
 231x230x230mm
 QUAST15DEM
 3 Hour Flat Glass 4000K IP65 IK10
 14.2W
 1453lm
 231x230x230mm
 QUAST15DEMPEC
  3 Hour Flat Glass 4000K IP65 IK10
  14.2W
  1453lm
  231x230x230mm
 QUAST15DPEC
 Flat Glass 4000K IP65 IK10
 14.2W
 1453lm
 231x230x230mm
   Alfresco 2.0
The design for Alfresco 2.0 is simple and classic and it will suit most wall mounted applications.
• 21W
• 1,050 - 2,100 Luminaire Lumens
• Efficacy up to 100 Im/W
• 4000K, CRI >80
• Lifetime >50,000hr, L70
• Anthracite Grey Die Cast Aluminium
       Part No. Description Wattage Luminaire Lumens Dimensions
  ALFCL21F
 LED Clear Face Standard Driver
 21W
 2100lm
 340x105mm
 ALFCL21FEM
 LED Clear Face 3 Hour Emergency
 21W
 2100lm
 340x105mm
 ALFCL21FPEC
  LED Clear Face c/w Photocell
  21W
  2100lm
  340x105mm
 ALFCL21FEMPEC
LED Clear Face 3 Hour Emergency
21W
2100lm
340x105mm
 ALFH21F
 LED Hooded Face Standard Driver
 21W
 1050lm
 340x105mm
 ALFH21FEM
 LED Hooded Face 3 Hour Emergency
 21W
 1050lm
 340x105mm
 ALFH21FPEC
  LED Hooded Face c/w Photocell
  21W
  1050lm
  340x105mm
 ALFH21FEMPEC
 LED Hooded Face 3 Hour Emergency
 21W
 1050lm
 340x105mm
