                    LIGHTING
Emergency Lighting
Arlington Pro
Versatile LED exit sign with drop blade with multitude of fixing options, for 3 hour maintained operation.
APPLICATIONS
• Corridors
• Exits
• Escape routes
TECHNICAL DETAILS
• 3 hours operation on battery power after mains power failure
• Can be wired up for either maintained or non-maintained operation
• Charge indicator lamp fitted
• 30m maximum viewing distance
• Self-test version compliant with BS5266 available. Suffix STM3 as listed
CONSTRUCTION
• Injection moulded white polycarbonate body
• Main body rotates 90 degrees to allow direct fixing to ceiling or a wall
• 5mm thick clear acrylic blade
• Changeable 0.25mm thick acrylic screen printed exit legends
• Supplied complete with either EURO legend “DOWN” arrow or ISO legend
“UP” arrow (ahead)
• Alternative direction legend packs also available as separate items
With Euro Legend
With ISO Legend
Head rotated 90o so it can be mounted to a wall
Wall Bracket
       Part No.
Description
 NAL/M3
 LED Maint 3Hr Blade Exit Sign Euro Down Legend
 NAL/STM3
 LED Maint 3Hr Blade Exit Sign Euro Down Legend Self Test
 NAL/M3/ISO-U
 LED Maint 3Hr Blade Exit Sign ISO Up Legend
 NAL/STM3/ISO-U
 LED Maint 3Hr Blade Exit Sign ISO Up Legend Self Test
Part No.
 Attachments
 NAL/RMK
Arlington Pro Recessed Mounting Kit
 NAL/SWMK
  Alington Pro Side Wall Mounting Kit
 NAL/WSK
 Arlington Pro Wire Suspension Kit
     Seneca Recessed Pro
Dedicated LED emergency fittings for recessed mounting
• 190 lumens
• Non-maintained operation
• Supplied complete with two lenses for
different light distributions:
- Wide, giving a circular light distribution - Oval, giving an oval light distribution
• Momentary manual test button fitted
• Self-test version, compliant with BS 5266
available. Suffix STM3 as listed
Seneca Surface Pro
Dedicated LED emergency fittings for surface mounting
• 186 lumens
• Non-maintained operation
• Supplied complete with two lenses for
different light distributions:
- Wide, giving a circular light distribution - Oval, giving an oval light distribution
• Momentary manual test button fitted
• Self-test version, compliant with BS 5266 available. Suffix STM3 as listed
Suspension Kit
Ceiling & Wall Mounting
Head positioned so it can be mounted to the ceiling
Recessed Mounting Kit
LITHIUM
                  Part No. Description
LITHIUM
LITHIUM
  Part No. Description
      NSC3/REC/NM3
Seneca Pro 3W LED Non-Maintained Recessed
NSC/SURF/NM3
Seneca Pro LED Non-Maintd 3Hr Surface Mount
    NSC3/REC/STNM3
Seneca Pro 3W LED Non-Maintained Recessed Self Test
NSC/SURF/STNM3
Seneca Pro LED Non-Maintd 3Hr Surface Mount Self Test
