                    LIGHTING
LED Battens
Phoenix
Premium LED batten available in 4’, 5’ and 6’, standard and high-output with additional options
APPLICATIONS
• Garages & workshops - Store rooms
• Corridors & circulation areas
CONSTRUCTION
• Conventional batten width steel body
• LEDs on metal-core PCB
• White gloss powder coated finish
• Opal polycarbonate LED diffuser
• BESA fixing points on rear
TECHNICAL DETAILS
• SIZE Standard and high-output versions available in 3 sizes:
4’, 30W, 3,810 lm, 127 l.lm/c.W 4’, 55W, 7,080 lm, 132 l.lm/c.W 5’, 40W, 4,955 lm, 130 l.lm/c.W 5’, 65W, 8,350 lm, 127 l.lm/c.W 6’, 50W, 6,070 lm, 126 l.lm/c.W 6’, 75W, 9,165 lm, 123 l.lm/c.W
• CRI >80
• CCT 4000K or 5000K
• Branded ENEC approved flicker free driver
• Emergency converted, sensor and dimming options available
Greenland
Premium polycarbonate IP66 weather-proof, non-corrosive fitting available in 4’, 5’ and 6’, standard and high-output with additional options
APPLICATIONS
• Industry, garages & workshops
• Food preparation areas
• External under-canopy use
CONSTRUCTION
• Polycarbonate base and opal diffuser
• Grade 316 stainless steel clips
• Reinforced drill points in base for direct surface fixing, or conduit suspension
• Stainless steel surface mounting clips
• Can also be suspended from wire/chain using clips provided
TECHNICAL DETAILS
• Single & twin rows of LEDs on metal core PCB
• 1x2’ 9.5W, 1,140 lm, 120 l.lm/c.W
• 2x2’ 17W, 2,128 lm, 123 l.lm/c.W
• 1x4’ 28W, 3,400 lm, 121 l.lm/c.W
• 2x4’ 45W, 6,370 lm, 140 l.lm/c.W
• 1x5’ 36W, 5,012 lm, 139 l.lm/c.W
• 2x5’ 73W, 9,865 lm, 135 l.lm/c.W
• 1x6’ 48W, 5900 lm, 122 l.lm/c.W
• 2x6’ 97W, 11652 lm, 121 l.lm/c.W
• CRI >80
• CCT 4000K in 2Ft, 4Ft, 5Ft & 6Ft or CCT 5000K in 4Ft & 5Ft
• Branded ENEC approved, flicker free driver
• Emergency converted, sensor and dimming options available
GENERATE VALUE
697
    Part No.
Description 4000K
 NPH30/LED/840
 LED 30W 4Ft 840
 NPH40/LED/840
 LED 40W 5Ft 840
 NPH50/LED/840
 LED 50W 6Ft 840
 NPH55/LED/840
  LED 55W 4Ft High Output 840
 NPH65/LED/840
LED 65W 5Ft High Output 840
 NPH75/LED/840
 LED 75W 6Ft High Output 840
 Part No.
  Description 5000K
 NPH30/LED/850
LED 30W 4Ft 850
 NPH40/LED/850
  LED 40W 5Ft 850
 NPH50/LED/850
LED 50W 6Ft 850
 NPH55/LED/850
 LED 55W 4Ft High Output 850
 NPH65/LED/850
  LED 65W 5Ft High Output 850
 NPH75/LED/850
 LED 75W 6Ft High Output 850SDCM<
            Part No.
Description 4000K
   NGN1X2/840
LED V2 Single 2Ft 840
  NGN1X4/840
LED V2 Single 4Ft 840
  NGN1X5/840
LED V2 Single 5Ft 840
  NGN1X6/840
LED V2 Single 6Ft 840
  NGN2X2/840
LED V2 Twin 2Ft 840
  NGN2X4/840
LED V2 Twin 4Ft 840
  NGN2X5/840
LED V2 Twin 5Ft 840
  NGN2X6/840
LED V2 Twin 6Ft 840
  Part No.
Description 5000K
  NGN1X4/850
LED V2 Single 4Ft 850
  NGN1X5/850
 NGN2X4/850
LED V2 Single 5Ft 850
 LED V2 Twin 4Ft 850
  NGN2X5/850
LED V2 Twin 5Ft 850
