LIGHTING
IP65 Non-Corrosive Luminaires
Weatherguard Plus
Still throwing fittings away at end of life? You dont need to with Weatherguard Plus. Taking IP65 corrosion resistant luminaires to the next level, Plus features high efficiency 100lm/W LEDs, and stainless steel clips. The drivers & LEDs are replaceable at the end of life, delivering environmental excellence.
• Unique future proofed plug & go replaceable LED modules
• Tough dust and waterproof polycarbonate body
• Energy saving 100 lm/W, high efficacy LEDs
• Lockable, robust stainless steel diffuser clips as standard
ra red arrow redarrow
Part No.
Description
Length
Wattage
Lumen Output
Colour Temperature (CCT)
WGP212
600mm Weatherguard Plus
664mm
12W
1200 lm
4000K
WGP224
600mm Weatherguard Plus
664mm
24W
2400 lm
4000K
WGP224E
600mm Weatherguard Plus with Emergency
664mm
24W
2400 lm
4000K
WGP425
1200mm Weatherguard Plus
1262mm
25W
2500 lm
4000K
WGP425E
1200mm Weatherguard Plus with Emergency
1262mm
25W
2500 lm
4000K
WGP450
1200mm Weatherguard Plus
1262mm
50W
5000 lm
4000K
WGP450E
1200mm Weatherguard Plus with Emergency
1262mm
50W
5000 lm
4000K
WGP535
1500mm Weatherguard Plus
1562mm
35W
3500 lm
4000K
WGP535E
1500mm Weatherguard Plus with Emergency
1562mm
35W
3500 lm
4000K
WGP570
1500mm Weatherguard Plus
1562mm
70W
7000 lm
4000K
WGP570E
1500mm Weatherguard Plus with Emergency
1562mm
70W
7000 lm
4000K
Weatherguard
Weatherguard is our latest and improved IP65 corrosion resistant luminaire designed for use with LED T8 tubes. Now with lockable stainless steel clips as standard, it sets the standard for IP65 non-corrosives for LED tubes. We recommend the use of Red Arrow’s range of T8 LED tubes for optimum performance.
• Designed specially for use with T8 LED lamps
• Quick fit, tool-less terminal block connections
• Tough and robust IP65 polycarbonate housing
• Strong and lockable stainless steel diffuser clips as standard
Part No.
Description
Length
Wattage
Lumen Output
Colour Temperature (CCT)
WG21
Weatherguard for 1 x 600mm LED tube
664mm for Single Tube
N/A
N/A
N/A
WG22
Weatherguard for 2 x 600mm LED tubes
664mm for Twin Tubes
N/A
N/A
N/A
WG41
Weatherguard for 1 x 1200mm LED tube
1262mm for Single Tube
N/A
N/A
N/A
WG42
Weatherguard for 2 x 1200mm LED tubes
1262mm for Twin Tubes
N/A
N/A
N/A
WG51
Weatherguard for 1 x 1500mm LED tube
1562mm for Single Tube
N/A
N/A
N/A
WG52
Weatherguard for 2 x 1500mm LED tubes
1562mm for Twin Tubes
N/A
N/A
N/A
T8LED210-40
600mm 10W 4000K T8 LED Tube
600mm
10W
900 lm
4000K
T8LED210-60
600mm 10W 6000K T8 LED Tube
600mm
10W
1000 lm
6000K
T8LED418-40
1200mm 18W 4000K T8 LED Tube
1200mm
18W
1700 lm
4000K
T8LED418-60
1200mm 18W 6000K T8 LED Tube
1200mm
18W
1800 lm
6000K
T8LED522-40
1500mm 22W 4000K T8 LED Tube
1500mm
22W
2100 lm
4000K
T8LED522-60
1500mm 22W 6000K T8 LED Tube
1500mm
22W
2200 lm
6000K
