P. 726

                    LIGHTING Recessed Modular Panels
 Rhombus & Rhombus Pro Backlit Panels
Rhombus and Rhobus Pro are the latest generation of recessed modular backlit LED panels, delivering exceptional performance and light quality. Both ranges offer unrivalled value for money.
• Rhombus achieves efficacy of 100 lm/W
• Rhombus Pro delivers energy saving 125 lm/W performance
• Rhombus Pro fitted with TP(a) diffuser as standard
• 3 year (Rhombus) and 5 year guarantee (Rhombus Pro)
Rhombus Backlit LED Panels
Rhombus PRO Backlit LED Panels
Bastion Edgelit Panels
Bastion is a comprehensive range of ultraslim edgelit recessed modular panels that are perfect for lighting any interior where void depth is an issue. Available in 4 sizes and 3
colour temperatures, Bastion features TP(b) diffusers, flicker free drivers and 5 year guarantee as standard.
• Ultra slim design, only 9mm deep, with TP(b) diffuser as standard
• Available in 4 body sizes to fit virtually any exposed T ceiling application
• Choice of 3000K, 4000K and 6000K all from stock
• 5 year guarantee and 50,000 hrs LED lifetime
  Part No.
Description
Wattage
Lumen Output
Colour Temperature (CCT)
Dimensions
 RB6636-40
  Rhombus 36W Recessed Modular Panel
  36W
  3600 lm
  4000K
  595 x 595mm
 RB6636-60
 Rhombus 36W Recessed Modular Panel
 36W
 3600 lm
 6000K
 595 x 595mm
     Part No.
Description
Wattage
Lumen Output
Colour Temperature (CCT)
Dimensions
 RBP6624-40
  Rhombus Pro 24W Recessed Modular Panel
  24W
  3000 lm
  4000K
  595 x 595mm
 RBP6624-60
 Rhombus Pro 24W Recessed Modular Panel
 24W
 3000 lm
 6000K
 595 x 595mm
 EMLEDKIT3
 3 Hr Emergency Conversion Kit
 -
 -
 -
 -
         Part No.
Description
Wattage
Lumen Output
Colour Temperature (CCT)
Dimensions
 BLP6636-30
 Bastion 600x600mm 36W 3000K LED Panel
 36W
 3240 lm
 3000K
 595 x 595mm
 BLP6636-40
 Bastion 600x600mm 36W 4000K LED Panel
 36W
 3240 lm
 4000K
 595 x 595mm
 BLP6636-60
 Bastion 600x600mm 36W 6000K LED Panel
 36W
 3240 lm
 6000K
 595 x 595mm
 BLP12660-30
  Bastion 600x1200mm 60W 3000K LED Panel
  60W
  5400 lm
  3000K
  595 x 1195mm
 BLP12660-40
Bastion 600x1200mm 60W 4000K LED Panel
60W
5400 lm
4000K
595 x 1195mm
 BLP12660-60
 Bastion 600x1200mm 60W 6000K LED Panel
 60W
 5400 lm
 6000K
 595 x 1195mm
 BLP12336-30
 Bastion 300x1200mm 36W 3000K LED Panel
 36W
 3240 lm
 3000K
 595 x 595mm
 BLP12336-40
 Bastion 300x1200mm 36W 4000K LED Panel
 36W
 3240 lm
 4000K
 595 x 595mm
 BLP12336-60
  Bastion 300x1200mm 36W 6000K LED Panel
  36W
  3240 lm
  6000K
  595 x 595mm
 BLP6326-30
Bastion 300x600mm 26W 3000K LED Panel
26W
2340 lm
3000K
295 x 595mm
 BLP6326-40
 Bastion 300x600mm 26W 4000K LED Panel
 26W
 2340 lm
 4000K
 295 x 595mm
 BLP6326-60
 Bastion 300x600mm 26W 6000K LED Panel
 26W
 2340 lm
 6000K
 295 x 595mm
 EMLEDKIT3
  3 Hr Emergency Conversion Kit
  -
  -
  -
  -
 LEDP-SMKW
Surface Mounting Kit 600x600mm
-
-
-
600x600mm
 LEDP-SMKW12
  Surface Mounting Kit 600x1200mm
  -
  -
  -
  600x1200mm
 LEDP-SMKW1230
 Surface Mounting Kit 300x1200mm
 -
 -
 -
 300x1200mm
