P. 728

                    LIGHTING LED Downlights
ULTIMUM LED Fire Rated
• The ROBUS ULTIMUM is our latest “dimmable as standard” downlight which is also Low Glare, IP65 and Fire rated
• The range includes 5W, with higher performance than halogen or LED “lamp in a can”, 7W for areas that need that little extra light, or 7W colour temperature selectable for an alternative CCT where use of the lit space might change
    • All versions provide extensive energy and maintenance cost savings to reduce CO2 emissions
Part No. Description
   RUL0530-01
ULTIMUM 5W Fire Rated Downlight 3000K, 60° beam angle, IP65, dimmable, c/w White trim
 RUL0540-01
 ULTIMUM 5W Fire Rated Downlight 4000K, 60° beam angle, IP65, dimmable, c/w White trim
 RUL05X0-01
 ULTIMUM 5W IP65 Fire Rated Downlight, colour selectable, white trim
 RUL070WIFI-01
  ULTIMUM CONNECT 7W IP65 WIFI Tunable Fire Rated Downlight
 RUL0730-01
ULTIMUM 7W IP65 Fire Rated Downlight, 3000k, white trim
 RUL0740-01
  ULTIMUM 7W IP65 Fire Rated Downlight, 4000k, white trim
 RUL07X0-01
 ULTIMUM 7W IP65 Fire Rated Downlight, colour selectable, white trim
      Accessories
ULTIMUM+
ULTIMUM TILT+
Part No. Description
  RULTRIM-03
 Polished Chrome Plastic Trim for ULTIMUM FRD Range
 RULTRIM-10
  Matt Black Plastic trim for ULTIMUM FRD Range
 RULTRIM-13
 Brushed Chrome Plastic Trim for ULTIMUM Range
          • Unique wattage selectable design with choices of 5W and 7W
• LEDchroic lens replicating halogen dichroic with uniform, shadow-free
light
• Complies with BS476 Part 21. Report and certificate from International
Fire Consultants (IFC)
• Designed and tested to retain the integrity of 30, 60 and 90 minute fire
rated ceilings - compliant with Building Regulations Parts B, C and E
• Adjustable tilt of 25° allows light to be precisely directed where required
• Colour temperature selectable; switch on the back of the fitting allows
selection between 2700/3000/4000/6000K
• LEDchroic lens replicating halogen dichroic with uniform,
shadow-free light
Accessories
Part No. Description
    RULT06X4-01 ULTIMUM TILT+ 6W IP65 Fire Rated Downlight CCT4 White Trim
  Part No. Description
    RUL050730-01
  Ultimum 5W/7W Dual Wattage IP65 Fire Rated Downlight 3000K White Trim
  Part No. Description
    RULTTRIM-13 ULTIMUM TILT+ Brushed Chrome Trim
   728
