P. 738

                    LIGHTING
Saxby - IkonPRO CCT Decking Kit
    PUSH FIT 3 SIZE MINIMUM VOID 4 COLOUR HEAD OPTIONS 80MM OPTIONS
IKONPRO CCT
Unique design, easy to fit decking kits
An addition to the popular IkonPRO recessed LED decking kit range, within each head there is a choice of colours. Featuring the unique design of removable and interchangeable heads, to change colour you simply turn the head 180o and reinsert into the loom. The Fresnel lenses improve lumen output, diffusing the spread of light evenly. Designed to be fitted and wired during the decking build stage without the heads, the supplied rubber caps protect the fitting from the elements until the decking is complete. Each individual IP67 head then simply plug in, adding the final touches to the decking design. Available in a variety of sizes and colours.
 Saxby IkonPRO CCT
Unique design, Easy to fit, plug and play decking lights with an IP67 rating • Constructed from stainless steel (304) & polycarbonate
   • 10 x 0.75W LED module (SMD) CCT • Min void: 80mm
3000K/4000K
6500K/BLUE
      5YR IP67 80 WALK WARRANTY CLASS 3 SMD RATED CRI OVER
Part No. Description K Lm Lm/W Dimensions Cut Out
UP TO
410
LUMENS
 IP67
RATED
 EASY
INSTALL
 EXCLUSIVE
DESIGN
          73347
3000/4000
120
16
Proj: 1mm Dia: 25mm
Dia: 20mm
      73348
73349
IkonPRO CCT 25mm kit IP67
 IkonPRO CCT 35mm kit IP67
IkonPRO CCT 45mm kit IP67
3000/4000
3000/4000
280
37
55
Proj: 1mm Dia: 35mm
Dia: 25mm
       410
Proj: 1mm Dia: 45mm
Dia: 32mm
       76615
IkonPRO CCT 25mm kit IP67
6500/Blue
120
16
Proj: 1mm Dia: 25mm
Dia: 20mm
       76616
76617
IkonPRO CCT 35mm kit IP67
IkonPRO CCT 45mm kit IP67
6500/Blue
6500/Blue
280
 410
37
55
Proj: 1mm Dia: 35mm
Proj: 1mm Dia: 45mm
Dia: 25mm
      Dia: 32mm
