Page 739 - Fegime - Electrical Product Guide Issue 1 V5
P. 739

                    LIGHTING
Saxby - Downlights
Saxby ShieldPRO CCT
High performance IP65 CCT downlight
• Matt white finish bezel included
• Compatible dimmer 75021 (150W)
PUSH FIT DETACHABLE TERMINAL CONNECTOR
Airflow cap
Allows insulation to be loosely placed over the fitting
Colour Changing Technology
Choose between 3000K, 4000K & 6000K. Dimmable
Super low 50mm profile
Suitable for shallow ceiling voids
Spring ceiling clips
Hold the ShieldPRO firmly in place
Interchangeable bezels
Matt white bezel included. Satin nickel, chrome and matt black available - simple twist & lock fitting system
              5YR IP65
FIRE RATED
6 COVER IN SDCM INSULATION
WARRANTY CLASS 2 RATED
Saxby ShieldECO 500 CCT
Fire rated, IP65, dimmable downlight
• Constructed from steel & acrylic
• 5W LED module (SMD)
• Min. void 67mm
• White bezel included
• Bezel options available
Can be covered with New integrated fast fix insulation
30,60,90 MINS
THREE WAY
 CCT SWITCH
  Fast and secure installation.
Loop in, loop out terminals
Allows for first fix wiring and easy removal for decorating
Choose between warm white (WW), cool white (CW) & daylight
white (DW)
60o 80 DIMMABLE BEAM CRI
       Part No. Description Finish K Lm Lm/W Dimensions Cut Out
  90376
 ShieldPRO
 Matt white
 3000/4000/6000
 800
 114
 H: 50mm Dia: 88mm
 70mm
 90377
  ShieldPRO Bezel
  Satin nickel
  -
  -
  -
  Proj: 3mm Dia: 88mm
   90378
 ShieldPRO Bezel
 Chrome
 -
 -
 -
 Proj: 3mm Dia: 88mm
  92513
 New ShieldPRO Bezel
 Matt black
 -
 -
 -
 Proj: 3mm Dia: 88mm
        500
LUMEN
     5YR
IP65
60o 80 DIMMABLE BEAM CRI
FIRE RATED 6 90 MINS SDCM
WARRANTY
CLASS 2 RATED
800
LUMEN
    Part No. Description Finish K Lm Lm/W Dimensions Cut Out
  92748
 ShieldECO 500 CCT 5W
 Matt white
 3000/4000/6000
 500
 100
 Proj: 3mm H: 70mm Dia: 81mm
 Dia 64mm
 95202
  ShieldECO Bezel
  Satin chrome
        H: 5.5mm Dia: 84mm
   95203
 ShieldECO Bezel
 Chrome
    H: 5.5mm Dia: 84mm
     Together we
739
GENERATE VALUE

   737   738   739   740   741
