                     LIGHTING Ceiling and Wall Bulkheads
Ceiling and Wall Bulkheads
START Surface IP66 is perfect for interior and exterior applications including residential and commercial entrance ways and corridors. It benefits from a robust design that meets IK10 requirement
• The range comes in two different colour temperatures (3000K & 4000K) and delivers up to 2500lm with efficiency up to 107lm/W (4000K)
• START Surface IP66 (Ø350mm) allows you to choose the light level you need and set it during the installation (only on non-dimmable version). It is available also in SensorDim and Emergency options
• START Surface IP66 (Ø300mm) is available also in SensorDim version, which enables additional energy savings
• Lifetime 50,000 hours
    Part No.
Description
Total System Power Consumption (W)
Lumen Output (lm)
Efficacy (lm/W)
Colour Temperature (K)
 0049284
  START Surface IP66 1050lm 830 IK10 Black
  12
  1050
  88
  3000
 0049285
START Surface IP66 1100lm 840 IK10 Black
12
1100
92
4000
 0049286
 START Surface IP66 1050lm 830 IK10 White
 12
 1050
 88
 3000
 0049287
  START Surface IP66 1100lm 840 IK10 White
  12
  1100
  92
  4000
 Ø300mm Sensor Dim
 0049288
 START Surface IP66 1050lm 830 IK10 MW SENS Black
 12
 1050
 88
 3000
 0049289
 START Surface IP66 1100lm 840 IK10 MW SENS Black
 12
 1100
 92
 4000
 0049290
 START Surface IP66 1050lm 830 IK10 MW SENS White
 12
 1050
 88
 3000
 0049291
  START Surface IP66 1100lm 840 IK10 MW SENS White
  12
  1100
  92
  4000
 Ø350mm
 0049000
 START Surface IP66 1450lm 830 IK10 White
 14.5
 1450
 100
 3000
 0049001
 START Surface IP66 1500lm 840 IK10 White
 14.5
 1500
 103
 4000
 0049002
 START Surface IP66 1450lm 830 IK10 Black
 14.5
 1450
 100
 3000
 0049003
  START Surface IP66 1500lm 840 IK10 Black
  14.5
  1500
  103
  4000
 0049016
START Surface IP66 2400lm 830 IK10 White
24
2400
100
3000
 0049017
 START Surface IP66 2500lm 840 IK10 White
 24
 2500
 104
 4000
 0049018
 START Surface IP66 2400lm 830 IK10 Black
 24
 2400
 100
 3000
 0049019
  START Surface IP66 2500lm 840 IK10 Black
  24
  2500
  104
  4000
 Ø350mm Emergency
 0049008
 START Surface IP66 1450lm 830 EM3 IK10 White
 14
 1450
 104
 3000
 0049009
 START Surface IP66 1500lm 840 EM3 IK10 White
 14
 1500
 107
 4000
 0049010
 START Surface IP66 1450lm 830 EM3 IK10 Black
 14
 1450
 104
 3000
 0049011
  START Surface IP66 1500lm 840 EM3 IK10 Black
  14
  1500
  107
  4000
 Ø350mm Sensor Dim
 0049004
 START Surface IP66 1450lm 830 MW SENS IK10 White
 14
 1450
 104
 3000
 0049005
  START Surface IP66 1500lm 840 MW SENS IK10 White
  14
  1500
  107
  4000
 0049006
START Surface IP66 1450lm 830 MW SENS IK10 Black
14
1450
104
3000
 0049007
 START Surface IP66 1500lm 840 MW SENS IK10 Black
 14
 1500
 107
 4000
 0049020
 START Surface IP66 2400lm 830 MW SENS IK10 White
 25
 2400
 96
 3000
 0049021
  START Surface IP66 2500lm 840 MW SENS IK10 White
  25
  2500
  100
  4000
 0049022
START Surface IP66 2400lm 830 MW SENS IK10 Black
25
2400
96
3000
 0049023
  START Surface IP66 2500lm 840 MW SENS IK10 Black
  25
  2500
  100
  4000
 Ø350mm Sensor Dim Emergency
 0049012
  START Surface IP66 1450lm 830 MW SENS EM3 IK10 White
  14
  1450
  104
  3000
 0049013
START Surface IP66 1500lm 840 MW SENS EM3 IK10 White
14
1500
107
4000
 0049014
  START Surface IP66 1450lm 830 MW SENS EM3 IK10 Black
  14
  1450
  104
  3000
 0049015
 START Surface IP66 1500lm 840 MW SENS EM3 IK10 Black
 14
 1500
 107
 4000
    Accessories
Part No. Description
  0049342
 START Surface IP66 300mm Eyelid Black
 0049343
 START Surface IP66 300mm Eyelid White
 0049032
 START Surface IP66 350mm Eyelid White
 0049033
  START Surface IP66 350mm Eyelid Black
 0049034
 START Surface IP66 350mm Grille White
 0049035
 START Surface IP66 350mm Grille Black
