P. 749

                    LIGHTING LED Tape & LED Controllers
F12-RGBW Series LED Tape
Flexible design solutions can be mastered with the RGBW Silicon encased LED tape providing both with RGB colour temperatures: 2500k, 3000k,4000k, 6000k.
 • Even LED RGB colour and white lighting
• Supplied with 3M tape as standard
• 60 LEDs per mtr (RGB and white in single chip)
• IP65 rating
• 50,000 hours working life
• Multiple applications for
commercial and residential environments
LED Controllers
LED Controllers
LED Controllers
•
• •
Precise LED binning enables 100% consistent colour temperature from batch to batch
Available in four white colour temperature
 24VDC
Part No. Lumens Power Colour Dimensions
  F12-RGBCW-24-60
 455LM/M
 19.2W/M
 RGBW, 6000K + RGB
 5000 x 12mm
 F12-RGBNW-24-60
 437LM/M
 19.2W/M
 4000K + RGB, RGBW
 5000 x 12mm
 F12-RGBSW-24-60
  428LM/M
  19.2W/M
  2500K + RGB, RGBW
  5000 x 12mm
 F12-RGBWW-24-60
 910LM/M
 19.2W/M
 3000K + RGB
 5000 x 12mm
    Part No.
Power
Input Voltage
Output Voltage
Output Current
Dimensions
 BLE-DIM
 48 ~ 96W per channel, 480W
 12 ~ 24VDC
 -
 5 x 4A
 145 x 46.5 x 16mm
 BLE-DIM-RC
  -
  -
  -
  -
  136.6 x 38.9 x 10.7mm
 CVDIM1
 4 x (60-180)W
 12 ~ 36VDC
 12 ~ 36VDC
 4 x 5A
 178 x 45 x 19mm
 DMXDIM
 3/4/5 x (60-180)W
 12 ~ 36VDC
 12 ~ 36VDC
 3/4/5 x 5A
 160 x 54 x 21mm
      • Suitable for indoor lighting
• User-friendly interface, easy and simple
• 10 Pre-set changing modes, with pause function • Capable of RGB colour adjustment
• 1 Synchronization function to ensure consistant
pattern changes.
• Use with one RGB controller to control multiple connnections
• Use with RGB18 only
operation
• Control up to 4 zones & set 4 scenes at each zone
IP63 LED Controllers
• Designed for extending quantity of RGB LED strip lengths that can be used togther
• Provides channel outuputs
• Easy installation
 Part No.
Power
Input Voltage
Output Voltage
Output Current
Dimensions
 RGBWIFI-4x5A
 4 x (60-180)W
 12 ~ 36VDC
 12 ~ 36VDC
 4 x 5A
 170 x 57 x 21mm
 SCD107W
  -
  5 ~ 24VDC
  5 ~ 24VDC
  5A
  86 x 40 x 6.5mm
 RGB18
 -
 6 ~ 24VDC
 6 ~ 24VDC
 White 4A, RGB 3x2.5A
 115 x 52 x 5mm
    Part No.
Input Voltage
Output Voltage
Output Current
Dimensions
  RGB-RP
  6 ~ 24VDC
  6 ~ 24VDC
  White 4A, RGB 3x2.5A
  85 x 21 x 8.5mm
