P. 747

                    LIGHTING
Commercial LED Lighting
J LINE 150W LED Highbay
• IP65 LED luminaire
• High system efficacy >140lm/W
• Instant start with no flickering
• Energy saving & low maintenance costs
GEN2-HB Series LED Highbay
• Long life ~ up to 50k hours
• Passive cooling for optimum thermal
management
• 5 years warranty
  Part No. IP Rated Lumens Power Colour Dimensions
    JLHB-150-5K IP65 20400LM 150W 5000K Ø343 x 154mm
   The genesis2, IP65 Highbay range offers Lumen packages up to 28400Lm. Easy single point mounting for ease of installations combined with 110 degree light distribution for simple retrofit in exsisting installs.
• IP65 main voltage LED light
• High system efficacy >140lm/W
• Instant start with no flickering
• Thermal design
• Energy saving & low maintenance costs
• On-site replaceable optics
LOWBAY+IP54 LED Lowbay
• IP54 main voltage LED ceiling light
• 0.6mm sheet steel powder coated white
• Alanod high reflective aluminium
• Instant start with no flickering
• Energy savings of 85% & low maintenance
costs
• Long life - average 50k hours
• Long life ~ up to 50k hours
• High pressure die-cast aluminium
• 5 years warranty
• High efficiency using Bridgelux, Edison 3030
LED chip
• PC transparent diffuser (optional opaque anti-glare diffuser AG1)
• Optional Daylight Harvesting, Corridor Function and Microwave Sensors
• High efficiency using Philips LumiLEDS LED chip and reflector system
 Part No. IP Rated Lumens Power Colour Dimensions
  GEN2-HB2
  IP65
  21000LM
  150W
  5000K
  Ø300 x 140mm
 GEN2-HB3
 IP65
 28400LM
 200W
 5000K
 Ø300 x 145mm
     Part No. IP Rated Lumens Power Colour Dimensions
  LOWBAY 120+ IP54
  IP54
  13840LM
  120W
  5000K
  800 x 330 x 90mm
 LOWBAY 180+ IP54-REV-A
 IP54
 20160LM
 180W
 5000K
 800 x 330 x 90mm
  * All of these variants are available for the LOWBAY 120 + IP54 and LOWBAY 180 + IP54 - However please note that the IP rating will be affected.
CONNECT LED Light Bars
• Slimline bar suitable for cabinet lighting, display and accent lighting etc.
• Easy installation, multiple configurations
• Simple and safe low voltage on/off control
• Reverse polarity protected
Accessories
• Simple link up capability, allowing up to 4 metres of lighting from 1 driver
• Rugged aluminium extrusion with easy
fit mounting points
• Suitable for 24VDC vehicle applications
CLC-1 F180 F90
  Part No. Lumens Power Colour Dimensions
  CON210
 280LM
 3.2W
 5600-7000K
 223.6 x 30 x 12.3mm
 CON210W
 225LM
 3.2W
 2800-3200K
 223.6 x 30 x 12.3mm
 CON310
 420LM
 5W
 5600-7000K
 323.6 x 30 x 12.3mm
 CON310W
  350LM
  5W
  2800-3200K
  323.6 x 30 x 12.3mm
 CON510
 620LM
 9W
 5600-7000K
 523.6 x 30 x 12.3mm
 CON510W
 520LM
 9W
 2800-3200K
 523.6 x 30 x 12.3mm
       Part No. Description
  CLC-1
 1500mm female to female extension cable
 CON-PIR
 5A PIR Sensor
 F180
  3A Straight connector
 F90
3A 90° Corner connector
 PS1
 3A 500mm input cable
 S180
  80mm 3A cable connector
 SW1
 3A Switch
      PS1 S180 SW1
 Together we
747
GENERATE VALUE
