                    LIGHTING Industrial Lighting
BLADE2 Series LED Floodlights
100~600W Lensed LED Floodlight
• High luminous efficacy using 3030 LED chips
• Super slim rugged design (maximum depth
60mm)
• Custom designed case for effective heat
dissipation
• Dimming options: 1~10V or DALI
• In house LED driver technology
• Impact resistant tempered glass
• 1.5 metre input cable for ease of
installation
• Bracket designed with +/-160° angle with 5° interval locking system
• Designed to eliminate water ingress
• Vented cable gland to reduce the risk of
condensation
• Optional NEMA Dusk to Dawn available • IP66 rating
• 5 years warranty
sunpower powerled power led
  Part No. IP Rated Lumens Power Colour Dimensions
  BLADE2-100
  IP66
  14000LM
  100W
  5000K
  315 x 245 x 57mm
 BLADE2-150
IP66
21000LM
150W
5000K
364 x 290 x 57mm
 BLADE2-200
  IP66
  28000LM
  200W
  5000K
  420 x 329 x 57mm
 BLADE2-300
 IP66
 33600LM
 300W
 5000K
 530 x 385 x 60mm
   FLEX-PIR Series Integral PIR LED Floodlights
 LED Remote Control Floodlight
• Suitable for security & general outdoor lighting applications
• Built-in PIR sensor with remote control
• Dusk to dawn function can be selected
instead of PIR movement detection through
the remote control
• PIR is bonded into the glass avoiding water
ingress
• Remote control operation
• Frosted lens to reduce glare
• Quality, long life 2835 LED chips
• Detection angle of 120° at a distance of
8 metres
• Designed to eliminate water ingress
• IP65 rating
• Flush heat sink with high surface area for
heat dissipation
 Part No. IP Rated Lumens Power Colour Dimensions
  FLEX-PIR10-5K
 IP65
 1000LM
 10W
 5000K
 124.5 x 93 x 27.5mm
 FLEX-PIR20-5K
 IP65
 2000LM
 20W
 5000K
 147 x 109 x 32.5mm
 FLEX-PIR30-3K
 IP65
 3000LM
 30W
 3000K
 208 x 148 x 39mm
 FLEX-PIR30-5K
  IP65
  5000LM
  30W
  5000K
  243 x 177.5 x 47mm
 FLEX-PIR50-3K
IP65
7000LM
50W
3000K
279 x 211 x 51.5mm
 FLEX-PIR50-5K
  IP65
  3000LM
  50W
  5000K
  208 x 148 x 39mm
 FLEX-PIR70-5K
 IP65
 5000LM
 70W
 5000K
 243 x 177.5 x 47mm
    ASTO Series 18W LED Bulkhead
18W LED Bulkhead
  • 120° Light distribution • Long service life
• Up to 100lm/W • Uses less power than fluorescent
• Ultra robust aluminium design
• IP65 Ingress protected
• Excellent optical design
FM = Full Moon HM = Half Moon
alternatives
• 3 hour emergency and microwave sensor options available
Part No. IP Rated Lumens Power Colour Dimensions
  ASTO-3K-FM
 IP65
 1800LM
 18W
 3000K
 124.5 x 93 x 27.5mm
 ASTO-4K-FM
  IP65
  1800LM
  18W
  4000K
  147 x 109 x 32.5mm
 ASTO-5K-FM
IP65
1800LM
18W
5000K
208 x 148 x 39mm
 ASTO-3K-HM
 IP65
 1800LM
 18W
 3000K
 243 x 177.5 x 47mm
 ASTO-4K-HM
  IP65
  1800LM
  18W
  4000K
  279 x 211 x 51.5mm
 ASTO-5K-HM
 IP65
 1800LM
 18W
 5000K
 208 x 148 x 39mm
