P. 87

                    CABLE MANAGEMENT
Clips & Screws
Safe-D U-Clips
      • •
Safe-D U-clips can be fitted direct-to-surface, or in non-metallic trunking systems
All can be secured to substrates by shot-fired nails or screw-fixings
• F-Clips are fire-rated flexible cable supports that are supplied in flat form, and can be folded in seconds to make a variety of shapes to most effectively secure cable installations
Clips
• Retro Clips are shaped to fit outside of existing non-metallic trunking installations
• They provide an easy-fit solution for trunkings that do not have internal fire-rated supports
           Part No. Description
   SAFE-D30/100
 Safe-D U-Clip 23mm Wide Pack of 100
 SAFE-D40/50
Safe-D U-Clip 31mm Wide Pack of 50
 SAFE-D50/50
  Safe-D U-Clip 46mm Wide Pack of 50
 SAFE-D30/RED
 Safe-D U-Clip 23mm wide Red Pack of 100
         • •
Metal T&E Clips
Safe-D T&E Grip Clips are user-friendly by a symmetrical design that makes it easy to hold the clip over T&E cable during installation... keeping finger and thumb away from hammer 2.5mm nail diameter
ps
• These Fixing Packs are ideal for EV charging cables
• Each pack contains 20x fire-rated screws for masonry, concrete & brickwork; with no wall- plug required
• The 20x Clips are produced from fire-rated steel, which can adjust to different cable diameters by a tight wrap & lock mechanism that gives installations a perfect finish
ing Clips
• 50mm long x 8mm max height
• Secure screw via eyelet, then adjust angle to suit the cables
• Tensioned clamp
Fire Rated Screws
• No wall plugs required
         Part No. Description
   SD-TE1.5/100
1.5mm Metal T&E Clip Pack of 100
 SD-TE2.5/100
  2.5mm Metal T&E Clip Pack of 100
 SD-TE4.0/100
 4.0mm Metal T&E Clip Pack of 100
 SD-TE6.0/100
 6.0mm Metal T&E Clip Pack of 100
      Together we
87
GENERATE VALUE
Safe-D F-Clips
Part No. Description
Safe-D Retro
  Part No. Description
      SAFEDFCLIP30/100
Safe-D F-Clip 30mm Pack of 100
SD-RETRO1/50
 SAFEDFCLIP50/50
Safe-D F-Clip 40mm Pack of 50
Safe-D F-Clip 50mm Pack of 50
Safe-D Retro Clip 16x16mm Pack of 50
   SAFEDFCLIP40/50
SD-RETRO2/50
Safe-D Retro Clip 25x16mm Pack of 50
    SD-RETRO3/20
Safe-D Retro Clip 40x25mm Pack of 20
    SD-RETRO4/20
Safe-D Retro Clip 50x50mm Pack of 20
  Metal T&E Cli
Fire Rated Spr
  Part No. Description
     SAFEDSPRING/50
Fire-Rated Spring Clip Pack of 50
   Part No. Description
   EVFIX10B
EV Fixing Pack
For cables 10-15mm dia
  EVFIX16B
EV Fixing Pack
For cables 16-21mm dia.
Part No. Description
     DFIX/100
Fire Rated Screws
40 x 5mm (L x Thread) - Pack of 100
  DFIX/100-P
Fire Rated Screws, Pan-Head
35 x 5.5mm (L x Thread) - Pack of 100
