                    CABLE MANAGEMENT Trunking
Odyssey Trunking
Odyssey is a 180x57mm three-compartment trunking system with a completely curved front profile designed with tamper-resistant covers and fittings and flush accessories to enhance the finished appearance. Odyssey’s curved profile is easy to clean and prohibits surface clutter. Also available with BIO integral antimicrobial properties.
• Available as an antimicrobial ‘Bio’ option
• Standard bend radius 25mm
• Coloured accessory boxes available to aid Part M compliance
• Fire clips available to secure cables within trunking
• Odyssey trunking assembly is manufactured using 62% recycled PVC-U
• Tamper resistant covers and fittings
• Flush fitting accessories
• Compliant up to Cat 7a
• Data fittings available for bend radius up to 65mm
• Adjustable data box 32-40mm
   Accessory Boxes
DD1WH
  Part No. Description Pack Size
  DD1WH
 Odyssey Trunking Assembly 180x57mm
 1 x 3m
 DD1210WH
 Coupler
 1
 DD1230WH
  End Cap
  2
 DD1310WH
Internal Bend
1
 DD1350HW
 External Bend
 1
 DD1330WH
 Internal Bend Adjustable 85-90 Degrees
 1
 DD1370WH
 External Bend Adjustable 85-90 Degrees
 1
 DD1410WH
  Flat Angle Up/Down
  1
 DD1430WH
Flat Tee 3 Part Assembly Up/Down
1
 DD1580MWH
 RCD Housing
 1
 FCOC
  Fire Clip Odyssey Centre Compartment
  50
 FCOO
 Fire Clip Odyssey Outer Compartment
 100
   DD1310WH
DD1350WH
   Part No. Description Pack Size
  DD1510WH
 1 Gang Accessory Box
 20
 DD1520WH
 2 Gang Accessory Box
 10
 DD1540WH
 1 Gang Adjustable Accessory box 32-40mm
 10
 DD1550WH
  2 Gang Adjustable Accessory box 32-40mm
  10
 DD1590WH
Accessory Box Adaptor
1 pair
 DD1510BU
 1 Gang Blue Accessory Box
 20
 DD1510CH
 1 Gang Charcoal Accessory Box
 20
 DD1520BU
  2 Gang Blue Accessory Box
  10
 DD1520CH
 2 Gang Charcoal Accessory Box
 10
    DD1510WH
DD1520WH
