P. 110

                    CABLE MANAGEMENT Trunking
Mono 10 Trunking
Mono 10 is a compact 100 x 50mm trunking that is perfectly suited for the smaller office or workshop area.
• One main compartment
• Can be subdivided
• Suitable for dado application and as a feeder trunking
• Compliant up to Cat 7a
• Standard bend radius 25mm
• Adjustable data box 32-40mm
• Fire clips available to secure cables within trunking
• Mono 10 trunking is manufactured using 77% recycled PVC-U
marshall tufflex
   Part No. Description Pack Size
  EPM10WH
 Mono 10 Trunking Assembly 100 x 50mm
 1 x 3m
 EC10WH
  Coupler
  2
 EEC10WH
End Cap
2
 EIB10WH
 Internal Bend
 2
 EXB10WH
 External Bend
 2
 EFA10WH
  Flat Angle Cover
  1
 EFT10WH
Flat Tee
1
 EDF2
  Dividing Tray
  8 x 3m
 FCM10C
 Fire Clip Mono 10 Centre Comp
 100
   Sterling Compact Trunking
Sterling Compact is an economical and stylish three-compartment trunking, compact in size and designed to fit within areas that may have trunking height restrictions. Previously known as Mono Plus 20, the base profile has been re-designed for independent access to each compartment.
• 140 x 50mm
• New base configuration for ease of installation
• One main compartment and two smaller outer compartments
• Suitable for dado application
• Fire clips available to secure cables within trunking
• New moulded flat angle and tee
• Fully compatible with the Mono Plus 20 range
• Assembly lengths are manufactured from 58% recycled PVC-U
   Part No. Description Pack Size
  EPM20WH
 Sterling Compact Trunking Asbly 140x50mm
 1 x 3m
 EMT20WH
 Trunking Base inc 2 Angled Outer Covers
 4 x 3m
 ETL1WH
 Main Compartment Cover
 8 x 3m
 EC20WH
  Coupler
  2
 EEC20WH
End Cap
2
 EIB20WH
 Internal Bend
 2
 EXB20WH
 External Bend
 2
 EFA20MWH
  Flat Angle - Up/Down
  1
 EFT20MWH
Flat Tee - Up/Down
1
 EMCB1
 Main Crossover Bridge
 5
 FCM20C
  Fire Clip Sterling Compact Centre Comp
  100
 FCM200
 Fire Clip Sterling Compact Outer Comp
 100
    110
