                                                CABLE MANAGEMENT
Cable Ladder
Swifts® Medium Duty (Topaz) Cable Ladder System
Straight Lengths - 3m
 Description
Straight Lengths (3m) Coupler Sets
Fitting to Fitting Coupler Sets
150mm Wide
ZL 150 F ZC F ZFC F
300mm Wide
ZL 300 F ZC F ZFC F
450mm Wide
ZL 450 F ZC F ZFC F
600mm Wide
ZL 600 F ZC F ZFC F
750mm Wide
ZL 750 F ZC F ZFC F
900mm Wide
ZL 900 F ZC F ZFC F
      Fitting to Straight Length Fastener Sets
 LF F M10P50
 LF F M10P50
 LF F M10P50
 LF F M10P50
 LF F M10P50
 LF F M10P50
  Flat Bends
 ZFB 150 A r F
 ZFB 300 A r F
 ZFB 450 A r F
 ZFB 600 A r F
 ZFB 750 A r F
 ZFB 900 A r F
  Inside Risers
 ZIR 150 A r F
 ZIR 300 A r F
 ZIR 450 A r F
 ZIR 600 A r F
 ZIR 750 A r F
 ZIR 900 A r F
 Z.2002-90 INSIDE RISER
 Outside Risers
 ZOR 150 A r F
 ZOR 300 A r F
 ZOR 450 A r F
 ZOR 600 A r F
 ZOR 750 A r F
 ZOR 900 A r F
   Equal Tees
  ZT 150 r R F
  ZT 300 r R F
  ZT 450 r R F
  ZT 600 r R F
  ZT 750 r R F
  ZT 900 r R F
 Unequal Tees
ZUT 150 B r R F
ZUT 300 B r R F
ZUT 450 B r R F
ZUT 600 B r R F
ZUT 750 B r R F
ZUT 900 B r R F
  Branch Piece
 ZB 150 300 R F
 ZB 300 300 R F
 ZB 450 300 R F
 ZB 600 300 R F
 ZB 750 300 R F
 ZB 900 300 R F
  4 Way Crosspieces
 ZX 150 r R F
 ZX 300 r R F
 ZX 450 r R F
 ZX 600 r R F
 ZX 750 r R F
 ZX 900 r R F
 K
 Straight Reducers
 -
 ZSR 300 K F
 ZSR 450 K F
 ZSR 600 K F
 ZSR 750 K F
 ZSR 900 K F
   Offset Reducers (Left Hand)
  -
  ZLR 300 K F
  ZLR 450 K F
  ZLR 600 K F
  ZLR 750 K F
  ZLR 900 K F
  Offset Reducers (Right Hand)
 -
 ZRR 300 K F
 ZRR 450 K F
 ZRR 600 K F
 ZRR 750 K F
 ZRR 900 K F
    Key: Selecting Medium Duty (Topaz) Fittings: Replace the letters shown in red with your choice from the following options :
A = Angle (°) : 90, 60, 45 or 30 | B = Branch width (mm) : 150, 300, 450, 600, 750, 900 | F = Finish : G (hot dip galvanised after manufacture), D = (deep galvanised), S (stainless steel) | K = Narrowed width when using a reducer (mm) : 150, 300, 450, 600, 750 | r = Radius (mm) : 300, 600
Swifts® Heavy Duty (Sapphire) Cable Ladder System
Straight Lengths - 3m
 Description
Straight Lengths (3m) Coupler Sets
Fitting to Fitting Coupler Sets
150mm Wide
PL 150 F PC F PFC F
300mm Wide
PL 300 F PC F PFC F
450mm Wide
PL 450 F PC F PFC F
600mm Wide
PL 600 F PC F PFC F
750mm Wide
PL 750 F PC F PFC F
900mm Wide
PL 900 F PC F PFC F
      Fitting to Straight Length Fastener Sets
 LF F M10P50
 LF F M10P50
 LF F M10P50
 LF F M10P50
 LF F M10P50
 LF F M10P50
  Flat Bends
 PFB 150 A r F
 PFB 300 A r F
 PFB 450 A r F
 PFB 600 A r F
 PFB 750 A r F
 PFB 900 A r F
  Inside Risers
 PIR 150 A r F
 PIR 300 A r F
 PIR 450 A r F
 PIR 600 A r F
 PIR 750 A r F
 PIR 900 A r F
 Z.2002-90 INSIDE RISER
  Outside Risers
  POR 150 A r F
  POR 300 A r F
  POR 450 A r F
  POR 600 A r F
  POR 750 A r F
  POR 900 A r F
 Equal Tees
PT 150 r R F
PT 300 r R F
PT 450 r R F
PT 600 r R F
PT 750 r R F
PT 900 r R F
  Unequal Tees
 PUT 150 B r R F
 PUT 300 B r R F
 PUT 450 B r R F
 PUT 600 B r R F
 PUT 750 B r R F
 PUT 900 B r R F
  Branch Piece
 PB 150 300 R F
 PB 300 300 R F
 PB 450 300 R F
 PB 600 300 R F
 PB 750 300 R F
 PB 900 300 R F
  4 Way Crosspieces
 PX 150 r R F
 PX 300 r R F
 PX 450 r R F
 PX 600 r R F
 PX 750 r R F
 PX 900 r R F
 K
  Straight Reducers
  -
  PSR 300 K F
  PSR 450 K F
  PSR 600 K F
  PSR 750 K F
  PSR 900 K F
  Offset Reducers (Left Hand)
 -
 PLR 300 K F
 PLR 450 K F
 PLR 600 K F
 PLR 750 K F
 PLR 900 K F
  Offset Reducers (Right Hand)
 -
 PRR 300 K F
 PRR 450 K F
 PRR 600 K F
 PRR 750 K F
 PRR 900 K F
    Key: Selecting Heavy Duty (Sapphire) Fittings: Replace the letters shown in red with your choice from the following options :
A = Angle (°) : 90, 60, 45 or 30 | B = Branch width (mm) : 150, 300, 450, 600, 750, 900 | F = Finish : G (hot dip galvanised after manufacture), D = (deep galvanised), S (stainless steel), E (powder coated) | K = Narrowed width when using a reducer (mm) : 150, 300, 450, 600, 750 | r = Radius (mm) : 300, 600
