                    CABLE MANAGEMENT
Metallic Flexible Conduit
Metallic Flexible Conduit
FSU - IP54 - Coated Steel
Construction: Galvanised steel, helically wound, flexible conduit with pvc coating. Colour black. Typical Applications: General factory wiring and connections to machines.
   Part No. Size Reel Length
  FSU20B
 20mm
 10, 25, 50m
 FSU25B
  25mm
  10, 25, 50m
 FSU32B
 32mm
 10, 25m
  FU - IP40 - Bare Steel
Construction: Galvanised steel, helically wound, flexible conduit. Colour zinc, self colour.
Typical Applications: Underfloor wiring in office blocks.
M - IP54 - Fixed External Thread Nickel Plated Brass
Two part fitting comprising shell and body with external thread. This fitting can be inserted into a knockout and secured with a locknut.
Other sizes available.
INHERENT LOW FIRE HAZARD
Other sizes available.
  Part No. Size Reel Length
  FU20
 20mm
 10, 25, 50m
 FU25
  25mm
  10, 25, 50m
 FU32
 32mm
 10, 25m
  S - IP54 - Swivel External Thread Nickel Plated Brass
Two part fitting comprising shell and body. The external thread swivels about the main body. Can be used with threaded entries, or knockout secured with a locknut.
       Part No. Size Metric Thread
Part No. Size Metric Thread
           FSU20-M20-M
 FSU32-M32-M
M - IP40 - Fixed External Thread Nickel Plated Brass
Two part fitting comprising shell and body with external thread. This fitting can be inserted into a knockout and secured with a locknut.
S - IP40 - Swivel External Thread Nickel Plated Brass
Two part fitting comprising shell and body. The external thread swivels about the main body. Can be used with threaded entries, or knockout secured with a locknut.
20mm
25mm
32mm
M20
M25
M32
FSU20-M20-S
FSU32-M32-S
20mm
32mm
M20
      FSU25-M25-M
FSU25-M25-S
25mm
M25
     M32
            Part No. Size Metric Thread
Part No. Size Metric Thread
           FU20-M20-M
     FU25-M25-M
20mm
25mm
32mm
M20
M25
M32
FU20-M20-S
FU25-M25-S
FU32-M32-S
20mm
25mm
32mm
M20
 M25
      FU32-M32-M
M32
