                    CABLE MANAGEMENT
Steel Cable Tray
Swifts® SS Light Duty Cable Tray
Straight Lengths - 3m
All SS straight lengths and fittings have integral couplers, no separate couplers are needed
Finishes and materials - Replace F with:
G Hot dip galvanised after manufacture PG Pre-galvanised S Stainless steel
Swifts® MRF Medium Duty Return Flange Cable Tray
Straight Lengths - 3m
     Part No. Width (mm) Depth (mm)
 SSL 50 F
 50
 12
 SSL 75 F
 75
 12
 SSL 100 F
 100
 12
 SSL 150 F
  150
  12
 SSL 225 F
 225
 12
 SSL 300 F
 300
 18
      Accessories including bends, tees and risers are available from Legrand
        Part No. Width (mm) Depth (mm)
 MRFL 50 F
 50
 25
 MRFL 75 F
  75
  25
 MRFL 100 F
100
25
 MRFL 150 F
 150
 25
 MRFL 225 F
 225
 25
 MRFL 300 F
  300
  25
 MRFL 450 F
450
25
 MRFL 600 F
 600
 25
 MRFL 750 F
  750
  25
 MRFL 900 F
 900
 25
   Finishes and materials - Replace F with:
G Hot dip galvanised after manufacture D Deep galvanised (not available in 50mm) PG Pre-galvanised steel S Stainless steel E Powder coated black RAL 9005
Swifts® SRF Heavy Duty Return Flange Cable Tray
 Accessories including bends, tees and risers are available from Legrand
   Straight Lengths - 3m
  Part No. Width (mm) Depth (mm)
 SRFL 75 F
 75
 50
 SRFL 100 F
 100
 50
 SRFL 150 F
 150
 50
 SRFL 225 F
 225
 50
 SRFL 300 F
  300
  50
 SRFL 450 F
450
50
 SRFL 600 F
 600
 50
 SRFL 750 F
  750
  50
 SRFL 900 F
 900
 50
  Finishes and materials - Replace F with:
G Hot dip galvanised after manufacture D Deep galvanised S Stainless steel E Powder coated black RAL 9005
Fixing Options
All fixing options to be used with standard coupler sets
Quick Bolt Fasteners
PG Pre-galvanised steel
 Accessories including bends, tees and risers are available from Legrand
  Pack of 100 M6 x 12 quick bolt fasteners with power tool nut driver
Swiftclip
Used to join straight lengths with coupler sets. Can also be used to join lengths to fittings.
Part No. Description
  QBF
  Dacromet finish
 QBFS
 Stainless steel finish
  Part No. Description
  SCLPG
  For use with PG tray up to and including 300 mm wide
 SCLG
 For use with G tray up to and including 300 mm wide
