                    CABLE MANAGEMENT
Distribution Trunking
Salamandre® Distribution Trunking
   Single Compartment Trunking Lengths - 3m
A safety return edge steel surface trunking system with strength and rigidity. Manufactured to BS EN 50085-2-1. Each trunking length is supplied with coupler (fitted), lid and lid fixings. Supplied as standard with push-fit diecast turnbuckle fixings. For screwfix or tamperproof screwfix, replace MGR with MSR or MSTR.
  Part No. Width (mm) Depth (mm)
 MGR22
 50
 50
 MGR32
 75
 50
 MGR33
 75
 75
 MGR42
  100
  50
 MGR43
100
75
 MGR44
 100
 100
 MGR62
 150
 50
 MGR63
  150
  75
 MGR64
 150
 100
   Part No. Width (mm) Depth (mm)
 MGR66
 150
 150
 MGR93 (1)
 225
 75
 MGR94 (1)
 225
 100
 MGR96 (1)
  225
  150
 MGR99 (1)
225
225
 MGR123 (1)
 300
 75
 MGR124 (1)
 300
 100
 MGR126 (1)
  300
  150
 MGR1212 (1)
 300
 300
   (1) Use additional cover straps (Cat. Nos. MGIP9TCS and MGIP12TCS) to achieve IP4X conformity
Fittings
IP4X 90° & 45° Bends
All bends are supplied with lid, lid fixings and a coupler prefitted with screws backed off, ready to accept slotted trunking. Z = Trunking size code.
 IP4X Top Lid 90° Bends - Gusset
IP4X Top Lid 90° Bends - Square
IP4X Inside Lid 90° Bends - Gusset
IP4X Inside Lid 90° Bends – Square
GENERATE VALUE
IP4X Outside Lid 90° Bends - Gusset
IP4X Outside Lid 90° Bends - Square
IP4X Top Lid 45° Bends
IP4X Inside Lid 45° Bends
IP4X Outside Lid 45° Bends
Trunking Couplers
IP4X Cover Strap
Clips over coupler joint to provide IP4X. Used in conjunction with IP4X fittings
Part No. Description
  MGIP Z CL
  1 Compartment
 MGIP Z CL2C
 2 Compartment
 MGIP Z CL3C
 3 Compartment
  Part No. Description
  MGIP Z CGL
 1 Compartment
 MGIP Z CGL2C
  2 Compartment
 MGIP Z CGL3C
 3 Compartment
  Part No. Description
  MGIP Z AGL
 1 Compartment
 MGIP Z AGL2C
  2 Compartment
 MGIP Z AGL3C
 3 Compartment
        Part No. Description
  MGIP Z ASL
 1 Compartment
 MGIP Z ASL2C
  2 Compartment
 MGIP Z ASL3C
 3 Compartment
  Part No. Description
  MGIP Z CSL
 1 Compartment
 MGIP Z CSL2C
  2 Compartment
 MGIP Z CSL3C
 3 Compartment
  Part No. Description
    MGR Z C
  Supplied with coupler screws fitted and backed off
      Part No. Description
  MGIP Z BGL
 1 Compartment
 MGIP Z BGL2C
  2 Compartment
 MGIP Z BGL3C
 3 Compartment
  Part No. Description
  MGIP Z AL
 1 Compartment
 MGIP Z AL2C
  2 Compartment
 MGIP Z AL3C
 3 Compartment
      Part No. Description
  MGIP2CS
 50mm cover strap
 MGIP3CS
 75mm cover strap
 MGIP4CS
  100mm cover strap
 MGIP6CS
150mm cover strap
 MGIP9CS
  225mm cover strap
 MGIP12CS
 300mm cover strap
   Part No. Description
  MGIP Z BSL
 1 Compartment
 MGIP Z BSL2C
  2 Compartment
 MGIP Z BSL3C
 3 Compartment
  Part No. Description
  MGIP Z BL
 1 Compartment
 MGIP Z BL2C
  2 Compartment
 MGIP Z BL3C
 3 Compartment
