                    CABLE MANAGEMENT Trunking
Challenger Trunking
Bendex Challenger is an easy to install 167 x 50mm trunking system suitable for installation at dado or skirting level dependent on the requirement. The system features a pre-drilled base a full range of accessories.
• Three segregated compartments
• Suitable for dado (System 1) and skirting (System 2) application
• Single piece moulded fittings
• Flat tees and flat angles with integral bend radius control
bendex
   Challenger Trunking - System 1
Challenger Trunking - System 2
Accessory Boxes
PVC-U accessory boxes for installation into the Bendex range of trunking systems.
• Accept standard UK accessories
• Standard screw fixing centres
XT1CWH
Part No. Description Pack Size
  XT1CWH
 Challenger System 1 Assembly 167x50mm
 1 x 3m
 XT1COWH
 Coupler
 2
 XT1ECWH
 End Cap
 2
 XT1IBWH
  Internal Bend
  2
 XT1EBWH
External Bend
2
 XT1FAWH
  Flat Angle Up or Down Complete
  1
 XT1FTWH
 Flat tee Up or Down Complete
 1
    Part No. Description Pack Size
  XT2CWH
  Challenger System 2 Assembly 167x50mm
  1 x 3m
 XT1COWH
Coupler
2
 XT2ECRWH
 End Cap Right
 2
 XT2ECLWH
 End Cap Left
 2
 XT2IBWH
 Internal Bend
 2
 XT2EBWH
  External Bend
  2
 XT2FAWH
 Flat Angle Up Complete
 1
 XT2FTWH
 Flat Tee Up Complete
 1
   XT2CWH
    Part No. Description Pack Size Box Depth
  XTBB1WH
  1 Gang Accessory Box
  20
  30mm
 XTBB2WH
 2 Gang Accessory Box
 10
 30mm
   XTBB1WH
XTBB2WH
