117CABLE MANAGEMENTTogether we GENERATE VALUESalamandre® Distribution TrunkingPart No. Width (mm) Depth (mm)MGR22 50 50MGR32 75 50MGR33 75 75MGR42 100 50MGR43 100 75MGR44 100 100MGR62 150 50MGR63 150 75MGR64 150 100Single Compartment Trunking Lengths - 3mA safety return edge steel surface trunking system with strength and rigidity. Manufactured to BS EN 50085-2-1. Each trunking length is supplied with coupler (fitted), lid and lid fixings. Supplied as standard with push-fit diecast turnbuckle fixings. For screwfix or tamperproof screwfix, replace MGR with MSR or MSTR. (1) Use additional cover straps (Cat. Nos. MGIP9TCS and MGIP12TCS) to achieve IP4X conformityDistribution TrunkingFittingsPart No. DescriptionMGIP Z AGL 1 CompartmentMGIP Z AGL2C 2 CompartmentMGIP Z AGL3C 3 CompartmentIP4X 90° & 45° BendsAll bends are supplied with lid, lid fixings and a coupler prefitted with screws backed off, ready to accept slotted trunking. Z = Trunking size code.IP4X Top Lid 90° Bends - GussetPart No. DescriptionMGIP Z ASL 1 CompartmentMGIP Z ASL2C 2 CompartmentMGIP Z ASL3C 3 CompartmentIP4X Top Lid 90° Bends - SquarePart No. DescriptionMGIP Z BGL 1 CompartmentMGIP Z BGL2C 2 CompartmentMGIP Z BGL3C 3 CompartmentIP4X Inside Lid 90° Bends - GussetPart No. DescriptionMGIP Z BSL 1 CompartmentMGIP Z BSL2C 2 CompartmentMGIP Z BSL3C 3 CompartmentIP4X Inside Lid 90° Bends – SquarePart No. DescriptionMGIP Z CGL 1 CompartmentMGIP Z CGL2C 2 CompartmentMGIP Z CGL3C 3 CompartmentIP4X Outside Lid 90° Bends - GussetPart No. DescriptionMGIP Z CSL 1 CompartmentMGIP Z CSL2C 2 CompartmentMGIP Z CSL3C 3 CompartmentIP4X Outside Lid 90° Bends - SquarePart No. DescriptionMGIP Z AL 1 CompartmentMGIP Z AL2C 2 CompartmentMGIP Z AL3C 3 CompartmentIP4X Top Lid 45° BendsPart No. DescriptionMGIP Z BL 1 CompartmentMGIP Z BL2C 2 CompartmentMGIP Z BL3C 3 CompartmentIP4X Inside Lid 45° BendsPart No. DescriptionMGIP Z CL 1 CompartmentMGIP Z CL2C 2 CompartmentMGIP Z CL3C 3 CompartmentIP4X Outside Lid 45° BendsPart No. DescriptionMGR Z C Supplied with coupler screwsfitted and backed offTrunking CouplersPart No. DescriptionMGIP2CS 50mm cover strapMGIP3CS 75mm cover strapMGIP4CS 100mm cover strapMGIP6CS 150mm cover strapMGIP9CS 225mm cover strapMGIP12CS 300mm cover strapIP4X Cover StrapClips over coupler joint to provide IP4X. Used in conjunction with IP4X fittingsPart No. Width (mm) Depth (mm)MGR66 150 150MGR93 (1) 225 75MGR94 (1) 225 100MGR96 (1) 225 150MGR99 (1) 225 225MGR123 (1) 300 75MGR124 (1) 300 100MGR126 (1) 300 150MGR1212 (1) 300 300
