P. 120

                    CABLE MANAGEMENT Conduit & Fittings
Class 4 Steel Conduit Tube
• Manufactured in accordance with BSEN61386-1:2008+A1:2019
• Authorised for use on London Underground to LU Standard 1-085 (for use on surface & sub-surface locations where applicable)
metpro
Contractor Pack
• Consists; 1 x 10mtr coil of PVC flexible conduit, PVC swivel adaptors
FCCP20
Steel Conduit Fittings
• Our malleable conduit boxes are all compliant to BSEN61386-1:2018+A1:2019
• Authorised for use on London Underground
        GCP20
FCCP25
Part No. Description
  GC20
 20mm x 3.75mtr Hot Dip Galv Conduit Tube
 GC25
  25mm x 3.75mtr Hot Dip Galv Conduit Tube
 GC20/3
 20mm x 3mtr Hot Dip Galv Conduit Tube
 GC25/3
 25mm x 3mtr Hot Dip Galv Conduit Tube
  Part No. Description
  FCCP20
  20mm PVC Contractor Pack
 FCCP25
 25mm PVC Contractor Pack
      Pre-Galvanised Conduit Tube
• Manufactured in accordance with BSEN61386-1:2008+A1:2019
• Authorised for use on London Underground to LU Standard 1-085 (for use on surface & sub-surface locations where applicable)
     Part No. Description
 Part No. Description
  MB1G
  20mm Terminal Box
  MB2G
  20mm Through Box
 MB8G
 25mm Terminal Box
 MB9G
 25mm Through Box
     Part No. Description
        GCP25
GCP20/3
Box Lid Screws
• Manufactured in accordance with BSEN61386-1:2008+A1:2019
• M4 brass box lid screws are available in lengths ranging from 6mm to 50mm
• All box lid screws are pan headed
20mm x 3.75mtr Pre-Galv Conduit Tube
25mm x 3.75mtr Pre-Galv Conduit Tube
  20mm x 3mtr Pre-Galv Conduit Tube
  GCP25/3
25mm x 3mtr Pre-Galv Conduit Tube
   Part No.
MB3G
 Description
20mm Angle Box
 Part No.
MB4G
 Description
20mm Tee Box
  MB10G
  25mm Angle Box
  MB11G
  25mm Tee Box
       Part No. Description
 Part No. Description
  MB5G
  20mm Intersection Box
  MB6G
  20mm Branch U Box
 MB12G
 25mm Intersection Box
 MB13G
 25mm Branch U Box
     Part No. Description
    BM6
M4 x 6mm Brass Box Lid Screw
   BM10
M4 x 10mm Brass Box Lid Screw
  BM12
M4 x 12mm Brass Box Lid Screw
  BM16
BM30
M4 x 16mm Brass Box Lid Screw
  BM20
M4 x 20mm Brass Box Lid Screw
  BM25
M4 x 25mm Brass Box Lid Screw
  M4 x 30mm Brass Box Lid Screw
Part No. Description
  MB7G
  20mm Branch Y Box
 MB14G
 25mm Branch Y Box
    BM35
M4 x 35mm Brass Box Lid Screw
   BM40
BM50
M4 x 40mm Brass Box Lid Screw
  M4 x 50mm Brass Box Lid Screw
   120
