118CABLE MANAGEMENTTogether we GENERATE VALUESwifts® Medium Duty (Topaz) Cable Ladder SystemStraight Lengths - 3mCable LadderDescription 150mm Wide 300mm Wide 450mm Wide 600mm Wide 750mm Wide 900mm WideStraight Lengths (3m) ZL 150 F ZL 300 F ZL 450 F ZL 600 F ZL 750 F ZL 900 FCoupler Sets ZC F ZC F ZC F ZC F ZC F ZC FFitting to Fitting Coupler Sets ZFC F ZFC F ZFC F ZFC F ZFC F ZFC FFitting to Straight Length Fastener Sets LF F M10P50 LF F M10P50 LF F M10P50 LF F M10P50 LF F M10P50 LF F M10P50Flat Bends ZFB 150 A r F ZFB 300 A r F ZFB 450 A r F ZFB 600 A r F ZFB 750 A r F ZFB 900 A r FInside Risers ZIR 150 A r F ZIR 300 A r F ZIR 450 A r F ZIR 600 A r F ZIR 750 A r F ZIR 900 A r FOutside Risers ZOR 150 A r F ZOR 300 A r F ZOR 450 A r F ZOR 600 A r F ZOR 750 A r F ZOR 900 A r FEqual Tees ZT 150 r R F ZT 300 r R F ZT 450 r R F ZT 600 r R F ZT 750 r R F ZT 900 r R FUnequal Tees ZUT 150 B r R F ZUT 300 B r R F ZUT 450 B r R F ZUT 600 B r R F ZUT 750 B r R F ZUT 900 B r R FBranch Piece ZB 150 300 R F ZB 300 300 R F ZB 450 300 R F ZB 600 300 R F ZB 750 300 R F ZB 900 300 R F4 Way Crosspieces ZX 150 r R F ZX 300 r R F ZX 450 r R F ZX 600 r R F ZX 750 r R F ZX 900 r R FStraight Reducers - ZSR 300 K F ZSR 450 K F ZSR 600 K F ZSR 750 K F ZSR 900 K FOffset Reducers (Left Hand) - ZLR 300 K F ZLR 450 K F ZLR 600 K F ZLR 750 K F ZLR 900 K FOffset Reducers (Right Hand) - ZRR 300 K F ZRR 450 K F ZRR 600 K F ZRR 750 K F ZRR 900 K FKey: Selecting Medium Duty (Topaz) Fittings: Replace the letters shown in red with your choice from the following options :A = Angle (°) : 90, 60, 45 or 30 | B = Branch width (mm) : 150, 300, 450, 600, 750, 900 | F = Finish : G (hot dip galvanised after manufacture), D = (deep galvanised), S (stainless steel) | K = Narrowed width when using a reducer (mm) : 150, 300, 450, 600, 750 | r = Radius (mm) : 300, 600Z.2002-90 INSIDE RISERKSwifts® Heavy Duty (Sapphire) Cable Ladder SystemStraight Lengths - 3mDescription 150mm Wide 300mm Wide 450mm Wide 600mm Wide 750mm Wide 900mm WideStraight Lengths (3m) PL 150 F PL 300 F PL 450 F PL 600 F PL 750 F PL 900 FCoupler Sets PC F PC F PC F PC F PC F PC FFitting to Fitting Coupler Sets PFC F PFC F PFC F PFC F PFC F PFC FFitting to Straight Length Fastener Sets LF F M10P50 LF F M10P50 LF F M10P50 LF F M10P50 LF F M10P50 LF F M10P50Flat Bends PFB 150 A r F PFB 300 A r F PFB 450 A r F PFB 600 A r F PFB 750 A r F PFB 900 A r FInside Risers PIR 150 A r F PIR 300 A r F PIR 450 A r F PIR 600 A r F PIR 750 A r F PIR 900 A r FOutside Risers POR 150 A r F POR 300 A r F POR 450 A r F POR 600 A r F POR 750 A r F POR 900 A r FEqual Tees PT 150 r R F PT 300 r R F PT 450 r R F PT 600 r R F PT 750 r R F PT 900 r R FUnequal Tees PUT 150 B r R F PUT 300 B r R F PUT 450 B r R F PUT 600 B r R F PUT 750 B r R F PUT 900 B r R FBranch Piece PB 150 300 R F PB 300 300 R F PB 450 300 R F PB 600 300 R F PB 750 300 R F PB 900 300 R F4 Way Crosspieces PX 150 r R F PX 300 r R F PX 450 r R F PX 600 r R F PX 750 r R F PX 900 r R FStraight Reducers - PSR 300 K F PSR 450 K F PSR 600 K F PSR 750 K F PSR 900 K FOffset Reducers (Left Hand) - PLR 300 K F PLR 450 K F PLR 600 K F PLR 750 K F PLR 900 K FOffset Reducers (Right Hand) - PRR 300 K F PRR 450 K F PRR 600 K F PRR 750 K F PRR 900 K FKey: Selecting Heavy Duty (Sapphire) Fittings: Replace the letters shown in red with your choice from the following options :A = Angle (°) : 90, 60, 45 or 30 | B = Branch width (mm) : 150, 300, 450, 600, 750, 900 | F = Finish : G (hot dip galvanised after manufacture), D = (deep galvanised), S (stainless steel), E (powder coated) | K = Narrowed width when using a reducer (mm) : 150, 300, 450, 600, 750 | r = Radius (mm) : 300, 600Z.2002-90 INSIDE RISERK
