119 Together we GENERATE VALUECABLE MANAGEMENTlinianLINIAN FireClip™LINIAN FireClip™Part No. Description Pack Quantity1LCB406 LINIAN FireClip, Single, Black, 4-6mm (CC3) 1001LCR406 LINIAN FireClip, Single, Red, 4-6mm (CC3) 1001LCW406 LINIAN FireClip, Single, White, 4-6mm (CC3) 1001LCC406 LINIAN FireClip, Single, Cream, 4-6mm (CC3) 1001LCCP406 LINIAN FireClip, Single, Copper, 4-6mm (CC3) 1001LCO406 LINIAN FireClip, Single, Orange, 4-6mm (CC3) 1001LCP406 LINIAN FireClip, Single, Purple, 4-6mm (CC3) 1001LCB608 LINIAN FireClip, Single, Black, 6-8mm (CC4) 1001LCR608 LINIAN FireClip, Single, Red, 6-8mm (CC4) 1001LCW608 LINIAN FireClip, Single, White, 6-8mm (CC4) 1001LCC608 LINIAN FireClip, Single, Cream, 6-8mm (CC4) 1001LCCP608 LINIAN FireClip, Single, Copper, 6-8mm (CC4) 1001LCO608 LINIAN FireClip, Single, Orange, 6-8mm (CC4) 1001LCP608 LINIAN FireClip, Single, Purple, 6-8mm (CC4) 1001LCY608 LINIAN FireClip, Single, Yellow, 6-8mm (CC4) 1001LCB911 LINIAN FireClip, Single, Black 9-11mm (CC5) 1001LCR911 LINIAN FireClip, Single, Red, 9-11mm (CC5) 1001LCW911 LINIAN FireClip, Single, White, 9-11mm (CC5) 1001LCC911 LINIAN FireClip, Single, Cream, 9-11mm (CC5) 1001LCCP911 LINIAN FireClip, Single, Copper, 9-11mm (CC5) 1001LCO911 LINIAN FireClip, Single, Orange, 9-11mm (CC5) 1001LCP911 LINIAN FireClip, Single, Purple, 9-11mm (CC5) 1001LCBLU911 LINIAN FireClip, Single, Blue, 9-11mm (CC5) 1001LCY911 LINIAN FireClip, Single, Yellow, 9-11mm (CC5) 1001LCW1114 LINIAN FireClip, Single, White, 11-14mm (CC6) 1001LCR1114 LINIAN FireClip, Single, Red, 11-14mm (CC6) 1001LCB1114 LINIAN FireClip, Single, Black, 11-14mm (CC6) 100LINIAN FireClip™. Equip yourself with an extraordinary upgrade in fire cable clip design that delivers major benefits in efficiency, safety and value for money. Suitable for: Round cables and PVC trunking, and anchor fixings for wire etc. Range to suit cable diameters from 4mm – 14mm. Support impressive tensile load of 24 kg.• For single and double cable applications• Replacement for cleats. Cleat size equivalent from CC3 to CC6. Consult cable manufacturer for further guidance• No plastic plugs, screws or washers required• 70% quicker to install than a saddle clip (3 times faster)• Suitable to use in various substrates (Stone, Concrete, Timber, Brick, Hollow Brick, Hollow Block, Heavy Block, Light Block, Masonry, Plasterboard) • Available Colours. Standard: Red/Black/White/Cream/Purple/Yellow/Orange/Galvanised/Copper/Blue. Custom orders: Available in over 200 RAL colours, MOQ and lead times may apply• Recommended spacing: 300mm, Hole Diameter* 6mm, Hole depth: 30mm, Supports a max tensile load of 24kg • Corrosion Resistant – UV Stable, 18th Edition Compliant, Fire-resistant >1200°C*Varies for best fixing according to the substrate See data sheet for further details.Part No. Description Pack Quantity1LCB682 LINIAN FireClip, Double, Black, 6-8mm (CC4x2) 1001LCR682 LINIAN FireClip, Double, Red, 6-8mm (CC4x2) 1001LCW682 LINIAN FireClip, Double, White, 6-8mm (CC4x2) 1001LCC682 LINIAN FireClip, Double, Cream, 6-8mm (CC4x2) 1001LCCP682 LINIAN FireClip, Double, Copper, 6-8mm(CC4x2) 1001LCO682 LINIAN FireClip, Double, Orange, 6-8mm (CC4x2) 1001LCP682 LINIAN FireClip, Double, Purple, 6-8mm (CC4x2) 1001LCY682 LINIAN FireClip, Double, Yellow, 6-8mm (CC4x2) 1001LCB9112 LINIAN FireClip, Double, Black, 9-11mm (CC5x2) 1001LCR9112 LINIAN FireClip, Double, Red, 9-11mm (CC5x2) 1001LCW9112 LINIAN FireClip, Double, White, 9-11mm (CC5x2) 1001LCC9112 LINIAN FireClip, Double, Cream, 9-11mm (CC5x2) 1001LCCP9112 LINIAN FireClip, Double, Copper, 9-11mm (CC5x2) 1001LCO9112 LINIAN FireClip, Double, Orange, 9-11mm (CC5x2) 1001LCP9112 LINIAN FireClip, Double, Purple, 9-11mm (CC5x2) 1001LCBLU9112 LINIAN FireClip, Double, Blue, 9-11mm (CC5x2) 1001LCY9112 LINIAN FireClip, Double, Yellow, 9-11mm (CC5x2) 1001LCGALV9112 LINIAN FireClip, Double, Galv, 9-11mm (CC5x2) 100Single FireClips Double FireClipsTMlinianclip.co.ukEel ctricCable orConduitEasy and simple stepsDrill a hole in yoursubstrateWe suggest aØ6mm hole at adepth of 30mm. forFireClips/T&EClips/Coaxial Clips or aØ10mm hole at adepth of 40mm forSuperClips.Slide the clipover the cable orconduitMake sure it'sseated in therounded area ofthe clip.Compress andpush it homePinch the legstogether and pushinto the hole byhand or tap with asoft hammer.Eel ctricCable orConduitDRILL HOLE SLIDE CLIP PUSH IT IN OVER CABLEHow to install LINIAN clips
