P. 125

                    CABLE MANAGEMENT
Channel Brackets and Accessories
  Flat Brackets
• Our flat brackets are all HDG finish and compliant to BS6946
• Compliant to LU Standard 1-085
(for use on surface & sub-surface locations)
Offset Angle Brackets
• Our offset angle brackets are all HDG finish and compliant to BS6946
• Compliant to LU Standard 1-085
(for use on surface & sub-surface locations)
Tray & Trunking Hangers
      • •
Produced to comply with
the requirements of BS6946
Metal Channel Support Systems
Authorised for use on London Underground to LU Standard 1-085
(for use on surface & sub-surface locations)
TTH100 TTH150
      MP2
MP4
MP6
MP3
MP5
MP7
MP16
MP23
MP20
MP57
         MP55
TTH225
TTH300
Part No. Description
  MP2
  Splice Plate 2 Hole
 MP3
Splice Plate 3 Hole
 MP4
 Splice Plate 4 Hole
 MP5
  Splice Plate 5 Hole
 MP6
Flat L Bracket
 MP7
  Flat T Bracket
 MP55
 Flat Crossover (4 Way) Bracket
  Part No. Description
  MP16
 45 Deg. T Bracket
 MP20
 45 Degree Obtuse Angle Bracket
 MP23
  45 Degree Acute Angle Bracket
 MP57
 2 Hole 2 Hole Hinged Angle Bracket
  Part No. Description
  TTH100
 100mm Tray Hanger
 TTH150
 150mm Tray Hanger
 TTH225
  225mm Tray Hanger
 TTH300
 300mm Tray Hanger
    90˚ Angle Brackets
• Authorised for use on
London Underground to
LU Standard 1-085 (for use on surface & sub-surface locations)
• Produced to comply with the requirements of BS6946 Metal Channel Support Systems
Z & U Profile Brackets
• Our Z profile & U profile brackets are all HDG finish and compliant to BS6946
• Compliant to LU Standard 1-085
(for use on surface & sub-surface locations)
            MP8
MP10
MP9
MP24
MP26 MP29
MP25
MP28
MP30
     MP11
MP12
Part No. Description
  MP24
  21mm Z Bracket
 MP25
41mm Z Bracket
 MP26
 82mm Z Bracket
 MP28
 21mm U Bracket
 MP29
  41mm U Bracket
 MP30
 82mm U Bracket
  Part No. Description
  MP8
 1 Hole 1Hole 90 Deg. Bracket
 MP9
 1 Hole 2 Hole 90 Deg. Bracket
 MP10
 1 Hole 3 Hole 90 Deg. Bracket
 MP11
  2 Hole 2Hole 90 Deg. Bracket
 MP12
 2 Hole 1 Hole 90 Deg. Bracket
