P. 159

                    CABLE MANAGEMENT Steel Cable Tray
UniKlip® Steel Cable Tray System
  Uniklip® is the patented, fast-fitting solution for Cable Tray Installation. Based on the same reliable strength and quality of Unitrunk, Uniklip® has been engineered with enhanced speed of installation and ease of use to provide a commercial advantage in a market where time efficiency is imperative. Lengths are supplied in 3m as standard - other sizes are available on request. Uniklip® is compatible up to and including 600mm tray widths - other sizes available on request.
All light duty tray lengths up to and including KLLD225T
come complete with swaged end for ease of coupling and to eliminate the need for couplers. KLLD300T and above require the use of couplers. A range of gauges is available on request.
Light Duty Cable Tray
Straight Couplers
• Sold in pairs
• Length - 200mm
• Supplied with 4x UniKlips
unitrunk uniklip
 Medium Duty Cable Tray
Heavy Duty Cable Tray
Part No. Size (mm)
  KLLD50T
 50
 KLLD75T
  75
 KLLD100T
100
 KLLD150T
 150
 KLLD225T
 225
 KLLD300T
  300
 KLLD450T
 450
 KLLD600T
 600
  Part No. Size (mm)
  KLMR50T
 50
 KLMR75T
  75
 KLMR100T
100
 KLMR150T
 150
 KLMR225T
 225
 KLMR300T
  300
 KLMR450T
 450
 KLMR600T
 600
  Part No. Size (mm)
  KLHR50T
 50
 KLHR75T
  75
 KLHR100T
100
 KLHR150T
 150
 KLHR225T
 225
 KLHR300T
  300
 KLHR450T
 450
 KLHR600T
 600
     Flat 90o Bends
      x4
Part No. Description
  KLMR/SC
  Medium Duty
 KLHR/SC
 Heavy Duty
  Part No. Description
  KLLD(50-600)FB90
 Light Duty
 KLMR(50-600)FB90
  Medium Duty
 KLHR(50-600)FB90
 Heavy Duty
   Flat Equal Tees
Flat 4 Way Equal Intersections
    Part No. Description
  KLLD(50-600)ET
 Light Duty
 KLMR(50-600)ET
  Medium Duty
 KLHR(50-600)ET
 Heavy Duty
  Part No. Description
  KLLD(50-600)FW
 Light Duty
 KLMR(50-600)FW
  Medium Duty
 KLHR(50-600)FW
 Heavy Duty
     Together we
159
GENERATE VALUE
