                    CABLE MANAGEMENT Cable Basket
EasyConnect Cable Basket
• Electro Zinc Plated
• Other lengths, dimensions and finishes are available on request,
including Hot Dip Galvanised and Stainless Steel
• No couplers required
Full bracket and accessories range available
easyconnect easy connect
   30mm Side Height
wire basket, wirebasket
60mm Side Height
100mm Side Height
Part No.
Width (mm)
Wire Ø (mm)
Length (m)
 EC 60.060 EZ
 60
 3.9
 3
 EC 60.100 EZ
 100
 3.9
 3
 EC 60.150 EZ
 150
 3.9
 3
 EC 60.200 EZ
  200
  3.9
  3
 EC 60.300 EZ
300
4.3
3
 EC 60.400 EZ
 400
 4.3
 3
 EC 60.450 EZ
 450
 4.6
 3
 EC 60.500 EZ
  500
  4.6
  3
 EC 60.600 EZ
 600
 4.6
 3
  Part No.
Width (mm)
Wire Ø (mm)
Length (m)
 EC 30.060 EZ
 60
 3.9
 3
 EC 30.100 EZ
 100
 3.9
 3
 EC 30.150 EZ
 150
 3.9
 3
 EC 30.200 EZ
  200
  3.9
  3
 EC 30.300 EZ
 300
 4.3
 3
  Part No.
Width (mm)
Wire Ø (mm)
Length (m)
 EC 100.150 EZ
 150
 4.3
 3
 EC 100.200 EZ
 200
 4.3
 3
 EC 100.300 EZ
 300
 4.3
 3
 EC 100.400 EZ
  400
  4.6
  3
 EC 100.500 EZ
 500
 4.6
 3
 EC 100.600 EZ
 600
 4.6
 3
  Fitting Joint Connector
• M-CLIC - Create Bends, Tees & Reducers • Supplied in packs of 100
Stand Off Bracket
• This is a 40mm high stand for floor mounted mesh basket and cable tray
• Which can also be used as a wall stand
• Finished in Pre-Galvanised Steel to (BS EN
ISO 1461)
• StainlessSteelandHotDipGalvanisedarealso available
Ceiling Support Bracket
• For fixing to horizontal concrete ceiling and walls
• Finished in Pre Galv
• Stainless Steel and Hot Dip Galvanised are also available
        Part No. Wire Ø
  MCLIC-ZF-3.9
 3.9
 MCLIC-ZF-4.3
  4.3
 MCLIC-ZF-4.8
 4.8
  Part No. Length (m)
  SOB100
 100 (mm)
 SOB150
 150 (mm)
 SOB225
 225 (mm)
 SOB300
  300 (mm)
 SOB450
 450 (mm)
 SOB600
 600 (mm)
  Part No. Pack Size Length (m)
  SOPC10SZ
 16
 100 (mm)
 SOPC15SZ
 12
 150 (mm)
 SOPC20SZ
  8
  200 (mm)
 SOPC30SZ
 8
 300 (mm)
