                    CABLE MANAGEMENT Cable Trunking
QuickFix Trunking
• Up to 6x faster installation
• IP4X compliant as standard
• Lengths are supplied with coupler, cover strap and Unibolts. Please note
cover straps are only required for Length to Length assembly and not for Fitting to Length assembly
Full fittings and accessories range available
Gusset Bend Outside Lid
Gussett Tee Top Lid
Intersection Box
GENERATE VALUE
Gussett Bend Top Lid
  Part No. Size (mm)
  TK22
  50x50
 TK33
75x75
 TK42
 100x50
 TK44
  100x100
 TK66
 150x150
        Part No. W (mm) H (mm) X (mm)
  GOB22
  50
  50
  25
 GOB33
75
75
25
 GOB42
 100
 50
 25
 GOB44
  100
  100
  25
 GOB66
 150
 150
 25
  Part No. W (mm) H (mm) X (mm)
  GTB22
  50
  50
  91
 GTB33
75
75
115
 GTB42
 100
 50
 140
 GTB44
  100
  100
  140
 GTB66
 150
 150
 193
    Gussett Bend Inside Lid
    Part No. W (mm) H (mm) X (mm)
  GIB22
  50
  50
  25
 GIB33
75
75
25
 GIB42
 100
 50
 25
 GIB44
  100
  100
  25
 GIB66
 150
 150
 25
  Part No. W (mm) H (mm) X (mm) Y (mm)
  GTT22
 50
 50
 25
 129
 GTT33
 75
 75
 25
 154
 GTT42
  100
  50
  25
  180
 GTT44
 100
 100
 25
 180
 GTT66
 150
 150
 25
 230
    Blank End
    Part No. W (mm) H (mm) X (mm)
  ITB22
 50
 50
 25
 ITB33
 75
 75
 25
 ITB42
 100
 50
 25
 ITB44
  100
  100
  25
 ITB66
 150
 150
 25
  Part No. W (mm) H (mm)
  BE22
 50
 50
 BE33
 75
 75
 BE42
 100
 50
 BE44
  100
  100
 BE66
 150
 150
