P. 168
CABLE MANAGEMENT 3 Compartment Dado Trunking
SLXL Lower Smoke Curved Dado
Marking the Next Generation in PVC Cable Management Solutions. Enhanced Safety as Standard
• PVC- LSF (lower smoke & fume) high impact 3 compartment dado trunking system, with an innovative formula, will reduce smoke emission by up to 65% in the first 4 minutes of a fire.
• The SLXL-LSF will meet and exceed all standards for the following structured cabling solutions: CAT5E, CAT6, CAT6A, CAT7, the latest CAT8 (UTP & shielded) and OM3 fibre.
dietzel univolt
Cable Management Systems
15%
SLXL lower smoke offers an ignition point up to 15% higher than standard PVC
Halogens are released at a considerably slower rate
Smoke release is reduced by up to 65% in the first 4 minutes of a fire
Part No. Description
SLXL65/210 LSF
210 x 65mm Lower Smoke Curved Dado CAT6/6A/7/8
SLXL65/210 LSF-LGL
210 x 65mm Lower Smoke Curved Dado - Light Grey Lid
SLIA LSF
Internal Adjustable Angle - Lower Smoke
SLOA LSF
External Adjustable Angle - Lower Smoke
SLFA LSF
Flat Angle - Lower Smoke
SLFT LSF
Flat Tee - Lower Smoke
SLC LSF
Joint Cover - Lower Smoke
SLE LSF
End Cap - Lower Smoke
SLB1-A LSF
Single Adjustable box 30mm-50mm - Lower Smoke
SLB2-A LSF
Twin Adjustable box 30mm-50mm - Lower Smoke
SLCR LSF
Cable Retainer - Lower Smoke
SLA LSF
Conduit/Mini Adaptor - Lower Smoke
SLR-PVC With Curved Profile
Univolt’s SLR - 3 compartment dado trunking is ideal for both power and data cabling and designed to suit any application. At 170mmx50mm the new curved profile offers greater data capacity, for the latest structured cabling* as well as DDA compliance with a light grey centre lid.
*Bend radius in accordance to the structure cabling manufacturer of 4x diameter of cable.
Cable Management Systems
SLIA SLB1-A
SLFA
pvc-lsf
Part No. Description Pack Qty
SLR 50/170
170mmx50mm 3 Comp Dado Trunking Curved -3M
1pc
SLR 50/170 LGL
170mmx50mm 3 Comp Dado Trunking Curved with light Grey Lid - 3M
1pc
RIE 50/170
Internal Angle
1pc
RAE 50/170
External Angle
1pc
RE 50/170
Stop End
1pc
RK 50/170
Coupler
1pc
RFW 50/170
Flat Angle
1pc
RFT 50/170
Flat Tee
1pc
SLB 1
One Gang Outlet Boxes - 28mm Deep
1pc
SLB 2
Twin Gang Outlet Boxes - 28mm Deep
1pc
SLB1-A
Single Adjustable box 30mm-50mm
1pc
SLB2-A
Twin Adjustable box 30mm-50mm-lower smoke
1pc
168
