                    CABLE MANAGEMENT
Bench, Power Poles and Posts
Power Poles & Posts
Univolt’s latest power pole is the perfect solution for buildings requiring both power and data in open locations, or workstations.
The sleek aluminum design comes with a new telescopic fixing arm, which extends the pole from its standard 3.5m to 3.95m, whilst allowing a quick fix installation, saving time on installation.
The power pole is available with light grey centre lid to achieve DDA compliance.
POWER POLE KIT
• New telescopic arm fixing for fast installation.
• PP2WT (powder coated white) - 3.5m long,
extendable up to 3.95m
• More modern design
• C/w 6 x 1 gang boxes (SLB1) including roof collar
• New design fixing for base
• New design fixing for ceiling
• Colours – Powder coated white (RAL9010).
• Additional extra 2.5m extension kit (PP2EXT),
enabling the power pole to be extended to a total of 6m
Cable Management Systems
PVC Bench Trunking
Univolt bench trunking is manufactured in a high impact white uPVC trunking, ideal for containing both power and data cables within vigorous environments.
The bench trunking comes in a 3-meter length as standard, accepting a single or twin adjustable back box, with the option to mount the bench trunking back-to-back.
DDA compliance is achieved by using a light grey centre lid.
BT-1G
BT-EB
Cable Management Systems
         BT-2G
BT-IB
  Part No. Description Dimensions (mm)
  PP2WT     Power Pole Kit 104 x 106 x 3500
  Part No. Description Pack Qty
  BT
 100mmx100mm PVC Bench Trunking C/W Lid - 3M Length
 1pc
 BT/BES
 End Cap
 1pc
 BT/BED
 Double End Cap
 1pc
 BT/BC
 Coupler
 1pc
 BT-1G
 1 Gang Bench Box
 1pc
 BT-1GD
  1 Gang Bench Box Double Sided
  1pc
 BT-2G
2 Gang Bench Box
1pc
 BT-2GD
 2 Gang Bench Box Double Sided
 1pc
 BT1+2G
 3 Gang Bench Box
 1pc
 BT1+2GD
  3 Gang Bench Box Double Sided
  1pc
 BT-IB
 Internal Angle
 1pc
 BT-EB
 External Angle
 1pc
     Part No. Description Dimensions (mm)
BT Bench trunking must only be used SLB1-A and SLB2-A back boxes.
  POWER POST KIT
• Double sided aluminium (white powder coated finish) trunking.
• Toe cap
• 2 x trunking lids (front and back)
• 3 x 1 gang mounting boxes (SLB1)
• Base fixing kit (with screws)
GENERATE VALUE
Accessories
SLB1-A SLB2-A
Part No. Description Pack Qty
  SLB1-A
 Single Socket Box
 1pc
 SLB2-A
  Twin Socket Box
  1pc
 MTW 50
 Divider - 3M
 1pc
      PP1     Power Post Kit 99 x 104 x 604
  Together we
169
   NEW RANGE
