                    WIRING ACCESSORIES Weatherproof Boxes
Junction Boxes
IP44 Plain Press-On-Lid -
Walls with Quick Entry Cable Glands
Technopolymer Surface Mounting Watertight Junction Boxes
A complete system of watertight surface mounting junction boxes made from ground breaking materials to provide innovative solutions.
gewiss
      Part No. Dimensions LxHxD (mm)
  GW44214
 100 x 100 x 120
 GW44215
  120 x 80 x 120
 GW44216
150 x 110 x 140
 GW44217
 190 x 140 x 140
 GW44218
 240 x 190 x 160
 GW44219
  300 x 220 x 180
 GW44220
 380 x 300 x 180
 GW44221
 L:460 x H:380 x D:180
  Part No. Dimensions LxHxD (mm)
  GW44204
 100 x 100 x 50
 GW44205
  120 x 80 x 50
 GW44206
150 x 110 x 70
 GW44207
 190 x 140 x 70
 GW44208
 240 x 190 x 90
 GW44209
  300 x 220 x 120
 GW44210
 380 x 300 x 120
 GW44211
 460 x 380 x 120
  Part No.
Dimensions Dia Ø x D (mm)
Entries
 GW44001
  65 x35
  4x23mm Dia Ø
 GW44002
 80 x35
 4x23mm Dia Ø
 GW44003
 L:80 x H:80 x D:40
 6x23mm Dia Ø
       IP44 Plain Press-On-Lid -
Walls with Quick Entry Cable Glands
Watertight Enclosures
• Versions for normal junction, special use and industrial use
• 3 degrees of protection: IP44, IP55, IP56
• 2 versions available in 11 sizes, featuring smooth walls or quick entry cable glands
IP56 Plain Deep Lid - Smooth Walls
IP56 Transparent Lid - Plain Walls
• 6 cover types available, clip/screw, quarter turn screw, blank/transparent, plain/deep
• 2 back mounting box depths, standard or high capacity to fit conduits up to ø50mm
• Grey RAL 7035
IP56 Plain Screwed Lid - Smooth Walls
Galvanised Steel Back Mounting Plate with Self Tapping Fixing Screws
Part No.
Dimensions Dia Ø x D (mm)
Entries
 GW44004
 100 x 100 x 50
 6x29mm Dia Ø
 GW44005
 120 x 80 x 50
 6x29mm Dia Ø
 GW44006
 150 x 110 x 70
 10x29mm Dia Ø
 GW44007
  190 x 140 x 70
  10x37mm Dia Ø
 GW44008
 240 x 190 x 90
 12x37mm Dia Ø
 GW44009
 300 x 220 x 120
 12x48mm Dia Ø
    Part No. Dimensions LxHxD (mm)
  GW44426
 150 x 110 x 70
 GW44427
 190 x 140 x 70
 GW44428
  240 x 190 x 90
 GW44430
 380 x 300 x 120
  Part No. Dimensions LxH Box Size (mm)
  GW44615
 190 x 140
 GW44616
 240 x 190
 GW44617
  300 x 220
 GW44618
 380 x 300
     27 Combi Range of IP55 Watertight Enclosures complete with System Devices
• Grey RAL 7035
Enclosure with 10A + 16A Switches
Enclosure with 13A Socket Outlet
   Part No.
Description
Dimensions LxHxD (mm)
 GW27831
 SP 1 Way Switch 10A
 66 x 82 x 65
 GW27832
 DP 1 Way Switch 16A
 66 x 82 x 65
 GW27833
  SP 2 Way Switch 10A
  66 x 82 x 65
 GW27834
 2x SP 2 Way Switch 10A
 66 x 82 x 65
    Part No.
 Description
 Dimensions LxHxD (mm)
   GW27843 13A Socket Outlet 66 x 82 x 65
