P. 208

                    WIRING ACCESSORIES RCD Sockets & Spurs
RCD Switched Sockets
• Mechanically latched, 10mA sensitivity
• Red & green dual flag system to show power on/off
• Fused for all fixed electrical appliances
• Cuts the power for added protection against electrocution
• Slim Profile
• Moulded front plate •PaFritsNsota.ndard 35mm back box
RCD Fused Spur
• Mechanically latched, 10mA sensitivity
• Red & green dual flag system to show power on/off
• Fused for all fixed electrical appliances
• Cuts the power for added protection against electrocution
• Scratch resistant urea front plate
• Fits 35mm standard back box
In-Line RCDs
• Heavy Duty
• IP65
• Re-wirable terminals
• 230V AC 50Hz
• Max operating
current 16A
RCD Switched Sockets
• Mechanical flag trip indicators
• Mechanically latched (passive)
Description
RCD Switched Sockets
• Mechanically latched, 10mA sensitivity
• Red & green dual flag system to show power on/off
• Fused for all fixed electrical appliances
• Cuts the power for added protection against electrocution,
• Complete with metal backbox
RCD Fused Spur
• Mechanically latched, 10mA sensitivity
• Red & green dual flag system to show power on/off
• Fused for all fixed electrical appliances
• Cuts the power for added protection against electrocution
• Complete with metal back box
In-Line RCD with IEC Lead
• Indoor use only
• IP20
• Fully portable
• 230V AC 50Hz
• Max operating current 10A
RCD Fused Spurs
• Mechanical flag trip indicator
• Mechanically latched (Passive)
      Part No. Description
  K21-MP10
  RCD Single Switched Socket
 K22-MP10
 RCD Twin Switched Socket
      K21-WP10
K22-WP10
RCD Single Switched Socket
  RCD Twin Switched Socket
      Part No. Description
 Part No. Description
    H92-MP10 RCD Fused Spur
      H92-WP10 RCD Fused Spur
      Part No. Description
  Part No. Description
  J63-X     In-Line RCD with IEC Lead
    J62-T
In-Line RCD Heavy Duty
  J62-Y
In-Line RCD Heavy Duty
      Part No. Description
    M22SW
RCD Switched Socket - White
Part No. Description
    M22SM
 M22W
M22M
RCD Switched Socket - Metalclad
    RCD Unswitched Socket - White
M92W
RCD Fused Spur - White
    RCD Unswitched Socket - Metalclad
M92M
RCD Fused Spur - Metalclad
     208
