                                    212WIRING ACCESSORIESTogether we GENERATE VALUEgewissWeatherproof BoxesPart No. DimensionsDia Ø x D (mm)EntriesGW44001 65 x35 4x23mm Dia ØGW44002 80 x35 4x23mm Dia ØGW44003 L:80 x H:80 x D:40 6x23mm Dia ØPart No. Dimensions LxHxD (mm)GW44214 100 x 100 x 120GW44215 120 x 80 x 120GW44216 150 x 110 x 140GW44217 190 x 140 x 140GW44218 240 x 190 x 160GW44219 300 x 220 x 180GW44220 380 x 300 x 180GW44221 L:460 x H:380 x D:180• Versions for normal junction, special use and industrial use• 3 degrees of protection: IP44, IP55, IP56• 2 versions available in 11 sizes, featuring smooth walls or quick entry cable glands• 6 cover types available, clip/screw, quarter turn screw, blank/transparent, plain/deep• 2 back mounting box depths, standard or high capacity to fit conduits up to ø50mm• Grey RAL 7035Junction BoxesTechnopolymer Surface Mounting Watertight Junction BoxesWatertight EnclosuresA complete system of watertight surface mounting junction boxes made from ground breaking materials to provide innovative solutions.IP44 Plain Press-On-Lid -Walls with Quick Entry Cable GlandsPart No. DimensionsDia Ø x D (mm)EntriesGW44004 100 x 100 x 50 6x29mm Dia ØGW44005 120 x 80 x 50 6x29mm Dia ØGW44006 150 x 110 x 70 10x29mm Dia ØGW44007 190 x 140 x 70 10x37mm Dia ØGW44008 240 x 190 x 90 12x37mm Dia ØGW44009 300 x 220 x 120 12x48mm Dia ØIP44 Plain Press-On-Lid -Walls with Quick Entry Cable GlandsPart No. Dimensions LxHxD (mm)GW44426 150 x 110 x 70GW44427 190 x 140 x 70GW44428 240 x 190 x 90GW44430 380 x 300 x 120IP56 Plain Deep Lid - Smooth WallsIP56 Transparent Lid - Plain WallsPart No. Dimensions LxHxD (mm)GW44204 100 x 100 x 50GW44205 120 x 80 x 50GW44206 150 x 110 x 70GW44207 190 x 140 x 70GW44208 240 x 190 x 90GW44209 300 x 220 x 120GW44210 380 x 300 x 120GW44211 460 x 380 x 120Part No. Dimensions LxH Box Size (mm)GW44615 190 x 140GW44616 240 x 190GW44617 300 x 220GW44618 380 x 300IP56 Plain Screwed Lid - Smooth WallsGalvanised Steel Back Mounting Plate withSelf Tapping Fixing Screws27 Combi Range of IP55 Watertight Enclosures complete with System Devices• Grey RAL 7035Enclosure with 10A + 16A SwitchesPart No. Description DimensionsLxHxD (mm)GW27831 SP 1 Way Switch 10A 66 x 82 x 65GW27832 DP 1 Way Switch 16A 66 x 82 x 65GW27833 SP 2 Way Switch 10A 66 x 82 x 65GW27834 2x SP 2 Way Switch 10A 66 x 82 x 65Enclosure with 13A Socket OutletPart No. Description DimensionsLxHxD (mm)GW27843 13A Socket Outlet 66 x 82 x 65
