P. 210

                    WIRING ACCESSORIES Switches, Sockets & Outlets
Sollysta 50A 1 Gang Double
Pole Switch with LED
• All terminal screws upward facing ease of installation
• Clearly printed terminal markings
• Mounting Box required: 46mm
Sollysta 45A Cooker
Control Unit with Neon
• Switch and Socket are double pole
• Terminal Capacity 2 x 6.0mm2
• Mounting box required: 46mm
Sollysta 50A 2 Gang Double
Pole Switch with LED
• 2 Gang Veritical with LED indicator
• All terminal screws upaward facing for ease of installation
• Mounting box required: 46mm
Sollysta 155/230V
Shaver Socket
• 115/230V shaver socket
• Shaver socket (vertical) designed for use in bathrooms and shower rooms
• Mounting box required: 46mm
Sollsta 20A Flex
Outlet Plate
• Singe screw fast fix cable clamp
• Suppled with M3.5 x 30mm fixing screws
• Protective red washer must be used under cable clamp to prevent damage to cable
Sollysta 45A Cooker
Control Unit
• Switch and Socket are double pole
• Terminal Capacity 2 x 6.0mm2
• Mounting box required: 46mm
                  Part No. Description
    WMDP50N
  Sollysta 50A Double Pole Switch 1 Gang with LED Indicator
  Part No. Description
    WMDP50VN
  Sollysta 50A Double Pole Switch with LED Indicator
  Part No. Description
    WMCC50 Sollysta 45A Cooker Control Unit
  Sollysta 3 Pole Isolator
Switch with Fan Symbol
• Terminal Capacity: 3 x 1.5mm2
• Suppled with M3.5 x 20mm fixing screws
• Mounting box required: 20 mm
             Part No. Description
  Part No. Description
    WMPS3PIF
  Sollysta 3 Pole Isolator Switch with Fan Symbol
        WMCC50N Sollysta 45A Cooker Control unit NEON
Sollysta 3 Pole
Isolator Switch
• Terminal Capacity: 3 x 1.5mm2
• Suppled with M3.5 x 20mm fixing screws
• Mounting box required: 20 mm
Sollysta 45A Cooker Cable
Outlet with Terminals
• Singe screw fast fix cable clamp
• Suppled with M3.5 x 30mm fixing screws
• Protective red washer must be used under cable clamp to prevent damage to cable
WMSO100 Sollysta 155/ 230V Shaver Socket
                Part No. Description
Part No. Description
  Part No. Description
    WMP50FO
  Sollysta 45A Cooker Cable Outlet with Terminals
          WMPS3PI Sollysta 3 Pole Isolator Switch
WMP2FO Sollsta 20A Flex Outlet Plate
   210
