368INDUSTRIAL CONTROLSTogether we GENERATE VALUEIndustrial ControlPart No. 400/415V (kW) Current SettingsGV2ME01 - 0.1 - 0.16GV2ME02 0.06 0.16 - 0.25GV2ME03 0.09 0.25 - 0.4GV2ME04 0.12 0.4 - 0.63GV2ME05 0.25 0.63 - 1.0GV2ME06 0.55 1.0 - 1.6GV2ME07 0.75 1.6 - 2.5GV2ME08 1.1 2.5 - 4.0GV2ME10 2.2 4.0 - 6.3GV2ME14 3.0 6.0 - 10.0GV2ME14 4.0 6.0 - 10.0GV2ME16 5.5 9.0 - 14.0GV2ME20 7.5 13.0 - 18.0GV2ME21 9.0 17.0 - 23.0GV2ME22 11.0 20.0 - 25.0GV2ME32 15.0 24.0 - 32.0Part No. 400/415V (kW) Current SettingsGV2P01 - 0.1 - 0.16GV2P02 0.06 0.16 - 0.25GV2P03 0.09 0.25 - 0.4GV2P04 0.12 0.4 - 0.63GV2P05 0.25 0.63 - 1.0GV2P06 0.55 1.0 - 1.6GV2P07 0.75 1.6 - 2.5GV2P08 1.1 2.5 - 4.0GV2P10 2.2 4.0 - 6.3GV2P14 3.0 6.0 - 10.0GV2P20 7.5 13.0 - 18.0GV2P21 9.0 17.0 - 23.0GV2P22 11.0 20.0 - 25.0GV2P32 15.0 24.0 - 32.0GV3P40 18.5 30.0 - 40.0GV3P50 22.0 37.0 - 50.0GV3P65 30.0 48.0 - 65.0Part No. Types of ContactsPosition Maximum No. PossibleGVAE1 1 NO or 1 NC (rev)Front 1GVAE11 1 NO & 1 NC Front 1GVAN11 1 NO & 1 NC Side (LH) 2GVAN20 1 NO & 1 NC Side (LH) 2GV2 Auxilliary BlocksGV2ME GV2PTeSys GV2 Motor Circuit BreakersGV2ME Thermal Magnetic Circuit Breakers GV2P Thermal Magnetic Circuit BreakersPart No. Description ContactXALK178 1 Red Mushroom Head Pushbutton 40mm dia Latching Twist to Release1 NCXALK188 1 Red Mushroom Head Pushbutton 40mm dia Latching Turn Key to Release1 NC%u2022 Grey base with yellow lid%u2022 IP66 conforming to IEC 60529%u2022 IP67%u2022 IP69%u2022 IP69K%u2022 IP65 DOL Polycarbonate Non-Reversing StartersPart No. 3Ph/400V (kW)AC-3 (A) Standard Voltages110V 230V 400VLE1D09** 4 9 F7 P7 V7LE1D12** 5.5 12 F7 P7 V7LE1D18** 7.5 18 F7 P7 V7LE1D25** 11 25 F7 P7 V7LE1D35** 15 35 F7 P7 V7TeSys Model D DOL StartersIP65 Emergency Stop StationsThermal Overload LRD** must be ordered separately.Pilot Devices - Harmony Style 4 (Metal)Part No. Description NO NCXB4BA21 (ZB4BZ101 + ZB4BA2) Black Pushbutton Head 1 -XB4BA31 (ZB4BZ101 + ZB4BA3) Green Pushbutton Head 1 -XB4BA42 (ZB4BZ102 + ZB4BA4) Red Pushbutton Head - 1XB4BA51 (ZB4BZ101 + ZB4BA5) Orange Pushbutton Head 1 -XB4BA61 (ZB4BZ101 + ZB4BA6) Blue Pushbutton Head 1 -XB4BD21 (ZB4BZ101 + ZB4BD2) 2 Position Stay Put Selector Switch 1 -XB4BD25 (ZB4BZ105 + ZB4BD2) 2 Position Stay Put Selector Switch 1 1XB4BD33 (ZB4BZ103 + ZB4BD3) 3 Position Stay Put Selector Switch 2 -XB4BG21 (ZB4BZ101 + ZB4BG4) 2 Position Stay Put Key Switch 1 -XB4BP31 (ZB4BZ101 + ZB4BP3) Green Pushbutton with Silicone Boot 1 -XB4BP42 (ZB4BZ102 + ZB4BP4) Red Pushbutton with Silicone Boot - 1XB4BS9442 (ZB4BZ102 + ZB4BS944) Key Release 40mm E Stop - 1XB4BS8442 (ZB4BZ102 + ZB4BS844) Twist Release 40mm E Stop - 1Complete Pushbuttons & Switches with Chromium Plated Metal BezelPart No. DescriptionXB4BVM1 (ZB4BVM1 + ZB4BV013) White 230V AC LED Pilot LightXB4BVM3 (ZB4BVM3 + ZB4BV033) Green 230V AC LED Pilot LightXB4BVM4 (ZB4BVM4 + ZB4BV043) Red 230V AC LED Pilot LightXB4BVM5 (ZB4BVM5 + ZB4BV053) Orange 230V AC LED Pilot LightXB4BVM6 (ZB4BVM6 + ZB4BV063) Blue 230V AC LED Pilot LightXB4BVB1 (ZB4BVB1 + ZB4BV013) White 24V AC/DC LED Pilot LightXB4BVB3 (ZB4BVB3 + ZB4BV033) Green 24V AC/DC LED Pilot LightXB4BVB4 (ZB4BVB4 + ZB4BV043) Red 24V AC/DC LED Pilot LightXB4BVB5 (ZB4BVB5 + ZB4BV053) Orange 24V AC/DC LED Pilot LightXB4BV61 (ZB4BV6 + ZB4BV01) White Direct Supply AC BA9 Pilot LightXB4BV63 (ZB4BV6 + ZB4BV03) Green Direct Supply AC BA9 Pilot LightXB4BV64 (ZB4BV6 + ZB4BV04) Red Direct Supply AC BA9 Pilot LightXB4BV65 (ZB4BV6 + ZB4BV05) Orange Direct Supply AC BA9 Pilot LightPilot Lights with Metal Bezel
