P. 372

                                    ENERGY CONTROL Microwave Detectors (Ceiling Only)
       CEILING MOUNTED
MICROWAVE DETECTORS
                                                                                 Corridor Ceiling Detectors
20761 CP Elec Ceiling microwave detectors Detectors.indd 1 Unlike fixed head microwave presence detectors
the MWS3A offers a unique presence/absence detection capability by using an adjustable head.
This incorporates an innovative locking mechanism to prevent tampering. By changing the angle of the head, different detection patterns can be achieved to suit the application. An integral sensitivity adjustment allows the detector to be fine tuned to its environment.
Compact Ceiling Mounted Detectors
    The MWS6 is a mid-range microwave presence/absence detector for the automatic control of lighting, heating and ventilation.
This detector has a low profile design which allows flush mounting into a ceiling tile, or surface mounting using a detector back box.
25/08/2021
11:35
Part No. Description
   MWS3A-PRM
PRM Switching, Adjustable Head, Long Range, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector
 MWS3A-PRM- 2CH
  PRM Switching, Adjustable Head, Long Range, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, 2-Channel
 MWS3A-DD
 DALI/DSI Digital Dimming, Adjustable Head, Long Range, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector,
up to 20 Drivers/Ballasts
 MWS3A-AD
 1–10V Analogue Dimming, Adjustable Head, Long Range, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, up to 10 Drivers/Ballasts
   Part No. Description
   MWS6-PRM
PRM Switching, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector
 MWS6-PRM-2CH
 PRM Switching, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, 2-Channel
 MWS6-DD
  DALI/DSI Digital Dimming, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, up to 20 Drivers/Ballasts
 MWS6-AD
 1–10V Analogue Dimming, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, up to 10 Drivers/Ballasts
   Miniature Flush Mounted Detectors
The MWS5 series of miniature microwave presence detectors provide automatic control of lighting loads with optional manual control.
As a standalone product, it is designed to be fitted unobtrusively into ceiling tiles or solid ceilings using the supplied clips. Three models are available: premium, direct dim, and analogue dim all of which will switch incandescent, fluorescent and compact fluorescent lighting.
Compact Surface Mounted Detectors
The MWS6SM is a surface mounted mid-range microwave presence/absence detector for the automatic control of lighting, heating and ventilation. The MWS6SM detects movement using a highly sensitive microwave detector.
    Part No. Description
   MWS5- PRM-SA-C
PRM Switching, Miniature, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, C/W Pre Wired PSU, Up To 10
 MWS5-DD- SA-C
  DALI/DSI Digital Dimming, Miniature, IP40, Ceiling, Flush Mounted, Micro- wave, Presence/Absence Detector, C/W PSU, up to 20 Drivers/Ballasts
 MWS5-AD- SA-C
 1–10V Analogue Dimming, Miniature, IP40, Ceiling, Flush Mounted, Micro- wave, Presence/Absence Detector, C/W PSU, up to 10 Drivers/Ballasts
  Part No. Description
   MWS6SM-PRM
PRM Switching, IP40, Ceiling, Surface Mounted, Microwave, Presence/Absence Detector
 MWS6SM-DD
  DALI/DSI Digital Dimming, IP40, Ceiling, Surface Mounted, Microwave, Presence/Absence Detector, up to 20 Drivers/Ballasts
 MWS6SM-AD
 1–10V Analogue Dimming, IP40, Ceiling, Surface Mounted, Microwave, Presence/Absence Detector, up to 10 Drivers/Ballasts
     372
