Vitesse Modular Lighting Connection System - Dimming
Vitesse Modular 6 Lighting System
   Supply lead to luminaire
   Permanent supply (230V)
Luminaire
Detector lead
Drop rod mounting option
PIR detector
               Switching module
20761 CP Elec Vitesse Images.indd Dimming
Supply lead to luminaire
PIR detector
1
Pluggable         Pre-wired option
19/08/2021
Presence Detectors
Add presence detection functionality to Vitesse Modular when required. Compact, flush mounted, ceiling PIR and Microwave presence detectors. No external control boxes are required as the unit is self contained.
     The Vitesse Modular system grows and adapts to suit the installation from 4-way to 16-way using the 4-way extender modules. Once Vitesse Modular is installed, modules can be added (or removed) depending on future requirements.
09:44
  Part No. Description
  VITM6-S
  Starter Module, Dimming, 6 Pole, 4 Outputs, Black/Grey Coding
 VITM6-S2
Starter Module, 6 Pole, 2 Outputs, Black/Grey Coding
 VITM6-E
 Extender Module, Dimming, 6 Pole, 4 Outputs, Black/Grey Coding
 BVITM6-S
 Starter Module, Dimming, 6 Pole, 4 Outputs, Black/Blue Coding
 BVITM6-S2
  Starter Module, 6 Pole, 2 Outputs, Black/Blue Coding
 BVITM6-E
Extender Module, Dimming, 6 Pole, 4 Outputs, Black/Blue Coding
 VITM6-SD5
  Pre-Wired, Corridor Module, Dimming, 5m Lead
 VITM6-SL1
 Pre-Wired, Starter Module Package, Dimming, 6 Pole, 4 Outputs, 4 Pole Ceiling Rose And Connector, 1m Lead
 BVITM6-SL1
 Pre-Wired, Starter Module Package, Dimming, 6 Pole, 4 Outputs, 4 Pole Ceiling Rose And Connector, 1m Lead, Black/Blue Coding
  Part No. Description
   VITM6-EBDSPIR-DD
 DALI/DSI Digital Dimming, Compact, IP40, Ceiling, Flush Mounted, PIR, Presence/Absence Detector, C/W 3m Vitm6 Lead
 VITM6-EBMHS-DD
 DALI/DSI Digital Dimming, Miniature, IP40, Ceiling, Flush/Surface Mounted, PIR, Presence Detector, C/W 3m Lead, C/W Pre-Wired PSU, up to 10 Drivers/Ballasts
 VITM6-MWS3A-DD
 DALI/DSI Digital Dimming, Adjustable Head, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector,
C/W 3m Lead, up to 20 Drivers/Ballasts
 VITM6-MWS6-DD
 DALI/DSI Digital Dimming, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, C/W 3m Lead, up to 20 Drivers/Ballasts
     A wide range of detector leads, Vitesse modular leads and connectors are available, contact your local branch for more information
