ENERGY CONTROL
Vitesse Modular Lighting Connection System - Switching
Vitesse Modular 4 Lighting System
Vitesse ModularTM
Lighting Connection System
Packed with innovative features, Vitesse Modular is a simple,
pluggable, cost effective method of providing power and control for
The system easily slots together and can be expanded up to 16 ways, making it adaptable to a wide variety of room layouts.
Once installed, modules can be added or removed to accommodate new layouts and uses.
vitesse modular lighting connection system
Switc2h0i7n6g1 CP Elec Vitesse Images.indd 2
Vitesse Modular 4 Lighting Connection System Switching Modules. The Vitesse Modular system grows and adapts to suit the installation from 4-way to 16-way using the 4-way extender modules.
Presence Detectors
Adds presence detection functionality to Vitesse Modular when required. Flush mounted ceiling PIR and Microwave presence detectors - including compact, miniature and adjustable head versions. No external control boxes are required as the unit is self contained.
2 Channel Switching Presence Detectors
19/08/2021
09:44
lighting installations.
Ideal for industrial, commercial and retail buildings.
Part No. Description
VITM4-EBDSPIR-PRM
PRM Switching, Compact, IP40, Ceiling, Flush Mounted, PIR, Presence/Absence Detector
VITM4-EBMHS-PRM
PRM Switching, Miniature, IP40, Ceiling, Flush/Surface Mounted, PIR, Presence Detector, C/W 3m Lead, C/W Pre-Wired PSU
VITM4-MWS3A-PRM
PRM Switching, Adjustable Head, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, C/W 3m Lead
VITM4-MWS6-PRM
PRM Switching, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, C/W 3m Lead
Part No. Description
VITM4-S2
Starter Module, Switching, 4 Pole, 2 Outputs
VITM4-S
Starter Module, Switching, 4 Pole, 4 Outputs
VITM4-E
Extender Module, Switching, 4 Pole, 4 Outputs
VITM4-SD5
Pre-Wired, Corridor Module, Switching, 4 Outputs, 5m
VITM4-SELVMOD
SELV Module, Switching
VITM4-SL1
Pre-Wired, Starter Module Package, Switching, 4 Pole, 4 Outputs, 4 Pole Ceiling Rose and Connector, 1m Lead
2 Channel Switching
The VITM4-2CH is a two channel, non-dimming distribution box for use in applications that require two independently switched lighting circuits, or lighting and ventilation circuits.
Part No. Description
MWS3A-PRM-2CH-NC
PRM Switching, Adjustable Head, Long Range, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, Normally Closed Fail-Safe Contacts, 2-Channel
MWS6-PRM-2CH-NC
PRM Switching, Compact, IP40, Ceiling, Flush Mounted, Microwave, Presence/Absence Detector, Normally Closed Fail-Safe Contacts, 2-Channel
Part No. Description
VITM4-S-2CH
Starter Module, Switching, 4 Pole, 4 Outputs, 2-Channel
VITM4-S-2CH-2S
Starter Module, Switching, 4 Pole, 4 Outputs, 2-Channel, 2 Supplies
VITM4-E-2CH
Extender Module, Switching, 4 Pole, 4 Outputs, 2-Channel
VITM4-E-2CH-2S
Extender Module, Switching, 4 Pole, 4 Outputs, 2-Channel, 2 Supplies
A wide range of detector leads, Vitesse modular leads and connectors are available, contact your local branch for more information
