Page 381 - Fegime - Electrical Product Guide Issue 1 V5
P. 381

                    ENERGY CONTROL
Switches
  Wall-Mounted 3-Wire PIR Occupancy Switch
• Detection range up to 10m
• Fits onto a 16mm deep wall box
• Can also be ceiling mounted
• Requires a neutral wire
• Adjustable time lag and photocell
• Switches up to 6 amps (1500W) of most loads,
including LED
Wall Or Ceiling-Mounted Microwave Detector Switch
Wall-Mounted 2-Wire PIR Occupancy Switch
• Detection range up to 10m
• Fits onto a 16mm deep wall box
• No neutral wire needed
• Manual override off push button
• Adjustable time lag and photocell
• Switches up to 6 amps (1500W) of fluorescent
or up to 2 amps (500W) of LED
• Minimum load 20W
• Supplied with load capacitor to augment
small loads
Wall Or Ceiling-Mounted Microwave Detector Switch
Ceiling Flush-Mounted Microwave Detector Switch
            Part No. Description
    WACE PIR Wall-mounted 3-wire PIR swicth
  Part No. Description
    WAPIR Wall-mounted 2-wire PIR swicth
  Part No. Description
    MWCEFL Flush-mounted microwave detector switch
        • 360° detection up to 12m diameter (ceiling mounted)
• Up to 9m detection range (wall mounted)
• IP67 rated enclosure
• Adjustable detection sensitivity
• Adjustable time lag and photocell
• Switches up to 2 amps (500W) of most types of load
GENERATE VALUE
• 360° detection up to 12m diameter (ceiling mounted)
• Up to 9m detection range (wall mounted) • IP67 rated enclosure
• Adjustable detection sensitivity
• Adjustable time lag and photocell
• Two outputs (same phase)
• Switches up to 10 amps (2500W) of
fluorescent or 6 amps (1500W) of LED (total)
• 360° detection up to 12m diameter
• Adjustable detection sensitivity
• Ideal for false or plasterboard ceilings • Adjustable time lag and photocell
• Switches up to 2 amps (500W) of LED
IP66 Rated Person Detector Switch
• Can be mounted on an exterior wall
• Detection range up to 10m
• Adjustable time lag and photocell
• Switches up to 6 amps (1500W) of fluorescent
or 2 amps (500W) of LED
Part No. Description
Part No. Description
  Part No. Description
  COPD     IP66 rated person detector switch
           MW2A IP67 Surface-mounted microwave switch 2A
MW6A2C IP67
Surface-mounted microwave switch 10A
