P. 390

                    ENERGY CONTROL Photocells, Isolators & Cut Outs
Photocells
Miniature Photocells
Miniature photocells offer discreet, efficient, and high performing streetlight control for installation within the luminaires or a separate small enclosure / box.
Nightowl
Photocell with timeclock and adjustable settings
        Fixing Wall Mounted
 Lux Settings
 Dusk Switch On Light Level:
3 - 10,000 Lux (Or Memory Setting)
 Time Settings Available On Unit
 Full Night, 2, 4, 6 And 8 Hour Run On Time After Dusk According To Lux Control Setting
 Maximum Load
 1000W Max (Resistive) 500W Max (Inductive)
 IP Rating (Installed)
  IP55
 Voltage / Frequency
 220V - 240V / 50 Hz
   Part No. SS14 – One Part SS14R – Two Part SS12SL
  Fixing Hole
  20mm
  20mm
  20mm
 70 Lux Switch-On Level
Yes
Yes
Yes
 55 Lux Option
 Yes
 N/A
 Yes
 35 Lux Option
 Yes
 N/A
 N/A
 Switching Ratio
  1:1.5 POS
  1:1.5 POS
  1:0.5 NEG
 Ingress Protection
IP66
 IP65
 IP65
  Voltage
 198-264
 Frequency
 47-63Hz
   Part No. Product Type Product Code Product Description
   WDF5001
  Time Programmable Photocell
  NIGHTOWL
 Compact light sensitive controller, designed to automatically switch on your lighting through a photo electric cell with easily adjustable, variable settings. Ideally suitable for the control of lights at the front door, garden, garage etc.
   Part No. Product Type Product Code Product Description
  F6085
 One Part Miniature Photocell
 SS14
 Miniature Photocell With 500mm Tails - 70 Lux Option
 F6087
  Two Part Miniature Photocell
  SS14-R
  Two-Part Miniature Photocells - 70 Lux Option
 F6075
 Miniature Photocell For Use In Bollards & Sign Lights
 SS12ASL
 For Bollards & Signs - Not Affected By Artificial Light Sources
e.g. Car Headlights, Streetlights Etc - 70 Lux Option
    Isolators and Cut Outs
 Providing a high level of safety and protection for the electrical connections within street lighting columns, amenity lighting & decorative lighting, Electric Vehicle charging and other power distribution applications. Lucy Zodion’s cut outs and isolators are designed to British Standards with a number of industry leading features that make them reliable, safe and compliant.
Please note these products are supplied without fuses but can be ordered separately dependent on what rating is required. Lawson Fuses, part of the Lucy Group, manufactures a full range of fuses compatible with Lucy Zodion street light cut outs & isolators.
Trojan Midi - Highly Configurable Street Light Isolator
  32 A providing one or two fused outputs
• 32A double pole DIN rail mounted isolator switch
• One or two fuses, BS88 MD maximum 25A
• Durable, robust thermoplastic enclosure
• Lockable fuse carrier & transparent access cover
• Fuse carrier terminals accept up to 16mm2
conductors
Plastic gland plate with 2 x 20mm grommets
• Din rail mounted earth terminal accepts 3 x 16mm2 conductors
• 6mm2 x 350mm tails fitted
• IP 44 rated
• Dimensions (in mm) H173 W90 D80
• Accreditations: IEC/EN 6-269-1, BS 6757, BS
6754, BS EN 60529, Low Voltage Directive, 2014/35/EU, RoHs Directive, 2011/65/EU
Other Isolators available. Our specialist ranges include:
• Trojan Mini – compact double pole isolator with 1 fuse for small areas e.g. small & narrow lighting columns amenity lighting
• Trojan Maxi – Double pole isolator with up to three modules or fuses e.g. Festive lighting applications, timers, surge protection etc
GENERATE VALUE
Part No. Product Type Product Code Product Description
   THM0014962
  Single Lantern Street Light Isolator
  NTM02-NEB2- NG06
300mm Tails
 32A Double Pole Isolator,
1x BS88 Fuse Carrier, Internal Earth Block, Plastic Plate And 2x20mm Grommets & 300mm Tails
 THM0034193
 Double Lantern Street Light Isolator
 NTM03-NEB2- NG06
300mm Tails
 32A Isolator, 2 X BS88 Fuse Carriers, Internal Earth Block, Plastic Plate and 2x20mm Grommets & 300mm Tails
    390
Together we
For other Photocell products available, our specialist ranges include:
• Heavy Duty - SS5DRHD - for high switching loads e.g. 2400W floodlights etc
• Highway Street Lighting - SS3, SS6 & ZCELL negative ratio, as specified by Local Authorities
• High Temperature - Miniature SS12CHT - for high temperature environments
• Part Night Off - SS9, SS19 – pre-programmed to switch off e.g. midnight to 5.30am
• Lux Levels – full range from 10 - 105 lux
