                    ENERGY CONTROL Isolators, Cut Outs & Connector Boxes
Isolators and Cut Outs
Street Light Cut Outs
Street lighting cut out with removable fuse carrier for all street lighting applications.
• SLF – Single fuse, Single pole single phase cut out
• Titan – Single or twin fuse, double pole, single or three phase input with multiple accessory options NB - Please note these products are supplied without fuses - please order separately dependant on rating
 SLF cutouts = Single Fuse, Single Pole Single Phase Cut Out (Separate Neutral & Earth - SNE)
Titan Cut Outs
Highly configurable streetlight cut out - Single or twin fuse, Double pole, single or three phase input with flexible accessory options.
  25A providing one fused output
  • Designed & tested in accordance with BS7654
• 25A maximum fuse rating
• Accepts LST fuse links to BS88
part 1, AC tag type
Other products available are:
• Max cable size 16mm2 stranded copper and 25mm2 solid aluminium conductor
• Integral gland plate
• Designed & tested in accordance with BS7654: IEC/EN60947-part 1
• 25A maximum fuse rating
• Accepts LST fuse links to BS88 part
1, AC tag type
• Loop in/loop out terminal blocks
• • • •
accept conductors up to 25mm2 Sealing wire facility
Cam lever with captive screw IP43
Dimensions (in mm) H150 W81 D65
Product Description
cable space and 2 & 3 way options
Spur off - NT10 e.g. bollard or sign light
3TT terminal blocks e.g. for additional spur on supply cable
(2TT)
• PaErltecNtoro.platedPbrroadsusctteTrmypienaPl rbolodcukcst Code
Part No. Product Type Product Code Product Description
   0260009009
  Single Lantern Street Light Cut Out
  SLF 25A SLCO TYPE 1 SNE
 Single Pole, Single Fuse Carrier, Earth Block and Plastic Plate & 2x 20mm Grommets
     THM0006032
  Single lantern Street Light Cut Out
  NT06-TT-NG12
  Double Pole, Single Fuse Carrier, Earth Block And Brass Plate & 2x 20mm Grommets
 THM0009901
 Double lantern Street Light Cut Out
 NT08-TT-NG12
 Double Pole, Twin Fuse Carrier, With Earth Block, Brass Plate and 2x 20mm Grommets
 • Lucy Zodion have DNO & IDNO approval products for G81 applications
• Clear cover versions available
• Combined Neutral & Earth (CNE) versions available
Connector Box
Surface mounting five-way (all insulated) connector box for single pole applications - used in all SMART meter installations and EV connections.
• Configurable options
• Three phase versions - NT12
& NT14
• Plastic gland plates
• 25mm grommets
• Tube & gland options
• Extension troughs for additional
• •
   • Electro-tin-plated terminal block for improved conductivity
• Serrated cable bores accept conductors up to 35mm2 csa
• Two M8 slotted head cable pinching screws per conductor
• Removable shields for unused
cable entries
GENERATE VALUE
• Dimensions: Height 65mm, Width 49.5mm, Depth 51.3mm
• Accreditations: BS 6757, BS 6754, BS EN 60529, Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/EU
Part No. Product Type Product Code Product Description
  0350012009
  5 Way Connector Box
  MLNS
  Surface Mounted Five-Way (All Insulated) Connector Box For Single Pole Applications
   Together we
