                    HEATING & VENTILATION Domestic Ventilation
QuietAir
Designed and engineered in Germany, every detail of the QuietAir range has been constructed to produce a high efficiency, low energy and practically silent extractor fan.
• Axial Fan
• Awarded Quiet Mark by Noise Abatement Society
• Two speed options available
• To fit duct diameters 100 mm (QT100) / 125 mm (QT125) / 150 mm
(QT150)
• Wall or ceiling mounted
• IP45 Rating
• Automatic ‘room refresh’ option (with T model)
quiet mark
airflow
       Part No.
Description
Flow Rate (l/sec)
Sound Pressure dB(A)
Power Consumption (W)
Dimensions (H x W x D mm)
 9041259
  QuietAir 100B - Basic
  21 / 25
  25 / 30
  5/ 9
  147 x 147 x 131
 9041260
QuietAir 100T - Timer
21 / 25
25 / 30
5/ 9
147 x 147 x 131
 9041261
 QuietAir 100HT - Humidity Timer
 21 / 25
 25 / 30
 5/ 9
 147 x 147 x 131
 9041262
 QuietAir 100MST - Motion Sensor Timer
 21 / 25
 25 / 30
 5/ 9
 147 x 147 x 131
 9041497
  QuietAir 120B - Basic
  42 / 47
  32 / 36
  10 / 13
  176 x 176 x 155
 9041498
QuietAir 120T - Timer
42 / 47
32 / 36
10 / 13
176 x 176 x 155
 9041499
 QuietAir 120HT - Humidity Timer
 42 / 47
 32 / 36
 10 / 13
 176 x 176 x 155
 9041500
 QuietAir 120MST - Motion Sensor Timer
 42 / 47
 32 / 36
 10 / 13
 176 x 176 x 155
 90000454
 QuietAir 150B - Basic
 61 / 72
 35 / 39
 6 / 10
 210 x 210 x 190
 90000455
  QuietAir 150T - Timer
  61 / 72
  35 / 39
  6 / 10
  210 x 210 x 190
 90000456
 QuietAir 150HT - Humidity Timer
 61 / 72
 35 / 39
 6 / 10
 210 x 210 x 190
 90000458
 QuietAir 150VS - Variable Speed
 13 / 72
 35 / 39
 6 / 10
 210 x 210 x 190
    Loovent eco
The Loovent eco range is a powerful discreetly styled Centrifugal fan. It is modular in design for ease of installation and maintenance ensuring effective ventilation with minimal noise and maximum efficiency.
• Centrifugal fan for toilets, kitchens and bathrooms
• Smallest 30 l/sec fan in its class
• Ideal replacement for old Loovents
• Can be recessed and surface mount in both portrait and landscape
• To fit duct diameter 100 mm
• Powerful low energy, 2-speed fan
• Available as intermittent and dMEV fan (both in 230V and 12V SELV
version)
• IPX5 rated (possible installation in zone 1)
    Part No.
Description
Flow Rate (l/sec)
Sound Pressure dB(A)
Power Consumption (W)
Dimensions (H x W x D mm)
 72684305
 Loovent Eco 230V Timer
 17 / 31
 29 / 47
 3.6 / 12
 167 x 187 x 138
 72684306
 Loovent Eco 230V Humidity Timer
 17 / 31
 29 / 47
 3.6 / 12
 167 x 187 x 138
 72684307
  Loovent Eco 230V Motion Sensor Timer
  17 / 31
  29 / 47
  3.6 / 12
  167 x 187 x 138
 72684309
Loovent Eco 12V SELV Timer
17 / 31
29 / 47
3.6 / 12
167 x 187 x 138
 72684310
 Loovent Eco 12V SELV Humidity Timer
 17 / 31
 29 / 47
 3.6 / 12
 167 x 187 x 138
 72684308
 Loovent Eco 230V dMEV Timer
 7/15 / 9/15 / 16/31
 25/46 / 25/46 / 28/46
 2.8/8.9 / 3/8.9 / 2.8/12
 167 x 187 x 138
 72684311
  Loovent Eco 230V dMEV Humidity Timer
  7/15 / 9/15 / 16/31
  25/46 / 25/46 / 28/46
  2.8/8.9 / 3/8.9 / 2.8/12
  167 x 187 x 138
 72684312
 Loovent Eco 12V SELV dMEV Timer
 7/15 / 9/15 / 16/31
 25/46 / 25/46 / 28/46
 2.8/8.9 / 3/8.9 / 2.8/12
 167 x 187 x 138
 72684313
 Loovent Eco 12V SELV dMEV Humidity Timer
 7/15 / 9/15 / 16/31
 25/46 / 25/46 / 28/46
 2.8/8.9 / 3/8.9 / 2.8/12
 167 x 187 x 138
