409ENERGY CONTROLTogether we GENERATE VALUEPhotocells, Isolators & Cut OutsPhotocellsFixing Wall MountedLux Settings Dusk Switch On Light Level: 3 - 10,000 Lux (Or Memory Setting)Time Settings Available On Unit Full Night, 2, 4, 6 And 8 Hour Run On Time After Dusk According To Lux Control SettingMaximum Load 1000W Max (Resistive) 500W Max (Inductive)IP Rating (Installed) IP55Voltage / Frequency 220V - 240V / 50 HzNightowlPart No. Product Type Product Code Product DescriptionWDF5001 Time Programmable PhotocellNIGHTOWL Compact light sensitive controller, designed to automatically switch on your lighting through a photo electric cell with easily adjustable, variable settings. Ideally suitable for the control of lights at the front door, garden, garage etc.For other Photocell products available, our specialist ranges include:%u2022 Heavy Duty - SS5DRHD - for high switching loads e.g. 2400W floodlights etc%u2022 Highway Street Lighting - SS3, SS6 & ZCELL negative ratio, as specified by Local Authorities%u2022 High Temperature - Miniature SS12CHT - for high temperature environments%u2022 Part Night Off - SS9, SS19 %u2013 pre-programmed to switch off e.g. midnight to 5.30am%u2022 Lux Levels %u2013 full range from 10 - 105 luxIsolators and Cut OutsProviding a high level of safety and protection for the electrical connections within street lighting columns, amenity lighting & decorative lighting, Electric Vehicle charging and other power distribution applications. Lucy Zodion%u2019s cut outs and isolators are designed to British Standards with a number of industry leading features that make them reliable, safe and compliant.Please note these products are supplied without fuses but can be ordered separately dependent on what rating is required. Lawson Fuses, part of the Lucy Group, manufactures a full range of fuses compatible with Lucy Zodion street light cut outs & isolators.%u2022 32A double pole DIN rail mounted isolator switch%u2022 One or two fuses, BS88 MD maximum 25A %u2022 Durable, robust thermoplastic enclosure%u2022 Lockable fuse carrier & transparent access cover%u2022 Fuse carrier terminals accept up to 16mm2conductorsPlastic gland plate with 2 x 20mm grommets%u2022 Din rail mounted earth terminal accepts 3 x 16mm2 conductors%u2022 6mm2 x 350mm tails fitted%u2022 IP 44 rated%u2022 Dimensions (in mm) H173 W90 D80%u2022 Accreditations: IEC/EN 6-269-1, BS 6757, BS 6754, BS EN 60529, Low Voltage Directive, 2014/35/EU, RoHs Directive, 2011/65/EUTrojan Midi - Highly Configurable Street Light Isolator32 A providing one or two fused outputsPart No. Product Type Product Code Product DescriptionTHM0014962 Single Lantern Street Light IsolatorNTM02-NEB2-NG06 300mm Tails32A Double Pole Isolator, 1x BS88 Fuse Carrier, Internal Earth Block, Plastic Plate And 2x20mm Grommets & 300mm TailsTHM0034193 Double Lantern Street Light IsolatorNTM03-NEB2-NG06300mm Tails32A Isolator, 2 X BS88 Fuse Carriers, Internal Earth Block, Plastic Plate and 2x20mm Grommets & 300mm TailsOther Isolators available. Our specialist ranges include:%u2022 Trojan Mini %u2013 compact double pole isolator with 1 fuse for small areas e.g. small & narrow lighting columns amenity lighting%u2022 Trojan Maxi %u2013 Double pole isolator with up to three modules or fuses e.g. Festive lighting applications, timers, surge protection etcPart No. SS14 %u2013 One Part SS14R %u2013 Two Part SS12SL Fixing Hole 20mm 20mm 20mm70 Lux Switch-On LevelYes Yes Yes55 Lux Option Yes N/A Yes35 Lux Option Yes N/A N/ASwitching Ratio 1:1.5 POS 1:1.5 POS 1:0.5 NEGIngress Protection IP66 IP65 IP65Voltage 198-264Frequency 47-63HzMiniature PhotocellsMiniature photocells offer discreet, efficient, and high performing streetlight control for installation within the luminaires or a separate small enclosure / box.Part No. Product Type Product Code Product DescriptionF6085 One Part Miniature Photocell SS14 Miniature Photocell With 500mm Tails - 70 Lux OptionF6087 Two Part Miniature Photocell SS14-R Two-Part Miniature Photocells - 70 Lux OptionF6075 Miniature Photocell For Use In Bollards & Sign LightsSS12ASL For Bollards & Signs - Not Affected By Artificial Light Sources e.g. Car Headlights, Streetlights Etc - 70 Lux OptionPhotocell with timeclock and adjustable settings
