Page 410 - Demo

410ENERGY CONTROLTogether we GENERATE VALUEIsolators, Cut Outs & Connector BoxesIsolators and Cut OutsHighly configurable streetlight cut out - Single or twin fuse, Double pole, single or three phase input with flexible accessory options.%u2022 Designed & tested in accordance with BS7654: IEC/EN60947-part 1%u2022 25A maximum fuse rating%u2022 Accepts LST fuse links to BS88 part 1, AC tag type %u2022 Loop in/loop out terminal blocks (2TT) %u2022 Electroplated brass terminal blocks accept conductors up to 25mm2%u2022 Sealing wire facility %u2022 Cam lever with captive screw%u2022 IP43 %u2022 Dimensions (in mm) H150 W81 D65Part No. Product Type Product Code Product DescriptionTHM0006032 Single lantern Street Light Cut OutNT06-TT-NG12 Double Pole, Single Fuse Carrier, Earth Block And Brass Plate & 2x 20mm GrommetsTHM0009901 Double lantern Street Light Cut OutNT08-TT-NG12 Double Pole, Twin Fuse Carrier, With Earth Block, Brass Plate and2x 20mm Grommets%u2022 Configurable options%u2022 Three phase versions - NT12 & NT14%u2022 Plastic gland plates%u2022 25mm grommets%u2022 Tube & gland options %u2022 Extension troughs for additional cable space and 2 & 3 way options%u2022 Spur off - NT10 e.g. bollard or sign light%u2022 3TT terminal blocks e.g. for additional spur on supply cableStreet Light Cut OutsStreet lighting cut out with removable fuse carrier for all street lighting applications.%u2022 Designed & tested in accordance with BS7654 %u2022 25A maximum fuse rating%u2022 Accepts LST fuse links to BS88 part 1, AC tag type%u2022 Max cable size 16mm2 stranded copper and 25mm2 solid aluminium conductor %u2022 Integral gland platePart No. Product Type Product Code Product Description0260009009 Single Lantern Street Light Cut OutSLF 25A SLCO TYPE 1 SNESingle Pole, Single Fuse Carrier, Earth Block and Plastic Plate & 2x 20mm GrommetsOther products available are:%u2022 Lucy Zodion have DNO & IDNO approval products for G81 applications%u2022 Clear cover versions available%u2022 Combined Neutral & Earth (CNE) versions available%u2022 SLF %u2013 Single fuse, Single pole single phase cut out%u2022 Titan %u2013 Single or twin fuse, double pole, single or three phase input with multiple accessory optionsSLF cutouts = Single Fuse, Single Pole Single Phase Cut Out (Separate Neutral & Earth - SNE)25A providing one fused outputNB - Please note these products are supplied without fuses - please order separately dependant on ratingTitan Cut OutsConnector BoxSurface mounting five-way (all insulated) connector box for single pole applications - used in all SMART meter installations and EV connections.%u2022 Electro-tin-plated terminal block for improved conductivity%u2022 Serrated cable bores accept conductors up to 35mm2 csa%u2022 Two M8 slotted head cable pinching screws per conductor%u2022 Removable shields for unused cable entries%u2022 Dimensions: Height 65mm, Width 49.5mm, Depth 51.3mm%u2022 Accreditations: BS 6757, BS 6754, BS EN 60529, Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/EUPart No. Product Type Product Code Product Description0350012009 5 Way Connector BoxMLNS Surface Mounted Five-Way (All Insulated) Connector Box For Single Pole Applications
