412ENERGY CONTROLTogether we GENERATE VALUEIsolators, Cut Outs & Connector BoxesIsolators and Cut OutsHighly configurable streetlight cut out - Single or twin fuse, Double pole, single or three phase input with flexible accessory options.• Designed & tested in accordance with BS7654: IEC/EN60947-part 1• 25A maximum fuse rating• Accepts LST fuse links to BS88 part 1, AC tag type • Loop in/loop out terminal blocks (2TT) • Electroplated brass terminal blocks accept conductors up to 25mm2• Sealing wire facility • Cam lever with captive screw• IP43 • Dimensions (in mm) H150 W81 D65Part No. Product Type Product Code Product DescriptionTHM0006032 Single lantern Street Light Cut OutNT06-TT-NG12 Double Pole, Single Fuse Carrier, Earth Block And Brass Plate & 2x 20mm GrommetsTHM0009901 Double lantern Street Light Cut OutNT08-TT-NG12 Double Pole, Twin Fuse Carrier, With Earth Block, Brass Plate and2x 20mm Grommets• Configurable options• Three phase versions - NT12 & NT14• Plastic gland plates• 25mm grommets• Tube & gland options • Extension troughs for additional cable space and 2 & 3 way options• Spur off - NT10 e.g. bollard or sign light• 3TT terminal blocks e.g. for additional spur on supply cableStreet Light Cut OutsStreet lighting cut out with removable fuse carrier for all street lighting applications.• Designed & tested in accordance with BS7654 • 25A maximum fuse rating• Accepts LST fuse links to BS88 part 1, AC tag type• Max cable size 16mm2 stranded copper and 25mm2 solid aluminium conductor • Integral gland platePart No. Product Type Product Code Product Description0260009009 Single Lantern Street Light Cut OutSLF 25A SLCO TYPE 1 SNESingle Pole, Single Fuse Carrier, Earth Block and Plastic Plate & 2x 20mm GrommetsOther products available are:• Lucy Zodion have DNO & IDNO approval products for G81 applications• Clear cover versions available• Combined Neutral & Earth (CNE) versions available• SLF – Single fuse, Single pole single phase cut out• Titan – Single or twin fuse, double pole, single or three phase input with multiple accessory optionsSLF cutouts = Single Fuse, Single Pole Single Phase Cut Out (Separate Neutral & Earth - SNE)25A providing one fused outputNB - Please note these products are supplied without fuses - please order separately dependant on ratingTitan Cut OutsConnector BoxSurface mounting five-way (all insulated) connector box for single pole applications - used in all SMART meter installations and EV connections.• Electro-tin-plated terminal block for improved conductivity• Serrated cable bores accept conductors up to 35mm2 csa• Two M8 slotted head cable pinching screws per conductor• Removable shields for unused cable entries• Dimensions: Height 65mm, Width 49.5mm, Depth 51.3mm• Accreditations: BS 6757, BS 6754, BS EN 60529, Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/EUPart No. Product Type Product Code Product Description0350012009 5 Way Connector BoxMLNS Surface Mounted Five-Way (All Insulated) Connector Box For Single Pole Applications
