HEATING & VENTILATION
Heating Cable & Insulation Boards
Undertile Heating Cable
Heating cables offer the ultimate flexibility for underfloor heating installation and you can select the output of the system by altering the cable spacing between the wires. They are most suited to small or complicatedly shaped rooms, and cables can be mixed and matched to provide the perfect coverage.
• Lifetime warranty
• BEAB Approved
• UKCA & CE marked
• 100% earth shield
• Anti-crush cable jacket
• Made in Denmark
ANTI-CRUSH
beab approved
Part No.
Description
Unit power (W)
Approximate coverage (m2)
PKC-3.0-0130
130W 3mm Undertile Heating Cable
130
0.8 - 1.1
PKC-3.0-0212
212W 3mm Undertile Heating Cable
212
1.2 - 1.7
PKC-3.0-0316
316W 3mm Undertile Heating Cable
316
1.8 - 2.4
PKC-3.0-0407
407W 3mm Undertile Heating Cable
407
2.5 - 3.0
PKC-3.0-0518
518W 3mm Undertile Heating Cable
518
3.1 - 3.6
PKC-3.0-0577
577W 3mm Undertile Heating Cable
577
3.7 - 4.2
PKC-3.0-0719
719W 3mm Undertile Heating Cable
719
4.3 - 5.2
PKC-3.0-0855
855W 3mm Undertile Heating Cable
855
5.3 - 6.3
PKC-3.0-1086
1086W 3mm Undertile Heating Cable
1086
6.4 - 7.5
PKC-3.0-1207
1207W 3mm Undertile Heating Cable
1207
7.6 - 8.5
PKC-3.0-1350
1350W 3mm Undertile Heating Cable
1350
8.6 - 9.5
PKC-3.0-1507
1507W 3mm Undertile Heating Cable
1507
9.6 - 10.8
PKC-3.0-1772
1772W 3mm Undertile Heating Cable
1772
10.9 - 12.5
PKC-3.0-1983
1983W 3mm Undertile Heating Cable
1983
12.6 - 13.9
PKC-3.0-2250
2250W 3mm Undertile Heating Cable
2250
14.0 - 15.5
PKC-3.0-2406
2406W 3mm Undertile Heating Cable
2406
15.6 - 16.8
Insulation Boards
These structural insulation boards increase the energy efficiency of underfloor heating and ensure a speedy warm up time. The are concrete faced, BBA Approved, and can be installed onto wooden floors with screws and washers (6mm and 10mm boards only), and onto concrete or tiled floors with flexible tile adhesive.
• 4, 6, 10 & 20mm thickness available
• BBA approved
• Made in the UK
• Concrete faced structual board
Part No.
Description
Board thickness
Board coverage (m2)
TTB-004-4PCK
4mm Thermal Insulation Board - 2.88sqm
4mm
2.88
TTB-004-5PCK
4mm Thermal Insulation Board - 3.60sqm
4mm
3.60
TTB-006-5PCK
6mm Thermal Insulation Board - 3.60sqm
6mm
3.60
TTB-006-6PCK
6mm Thermal Insulation Board - 4.32sqm
6mm
4.32
TTB-006-7PCK
6mm Thermal Insulation Board - 5.04sqm
6mm
5.04
TTB-006-8PCK
6mm Thermal Insulation Board - 5.76sqm
6mm
5.76
TTB-010-4PCK
10mm Thermal Insulation Board - 2.88sqm
10mm
2.88
TTB-010-5PCK
10mm Thermal Insulation Board - 3.60sqm
10mm
3.60
TTB-010-6PCK
10mm Thermal Insulation Board - 4.32sqm
10mm
4.32
TTB-010-7PCK
10mm Thermal Insulation Board - 5.04sqm
10mm
5.02
TTB-020-0004
20mm Thermal Insulation Board - 3.60sqm
20mm
3.60
Accessories
Part No. Description
TTB-111-0090
90m roll TTB Reinforcement Tape
TTB-111-1000
25mm Screws and Washers for TTB x 50 Screws
