                                    452HEATING & VENTILATIONTogether we GENERATE VALUEgreenwood airvacIntermittent Extract Ventilation FansUnity CV2.1Part No. Description IP VoltageCV2.1 Ultra Low Energy dMEV/Continuously running fan with Greenwood CommissionSMART™ technology and optional SMART Humidity and Timer options set-up at installation IPX4 CeilingIPX5 Wall220–240VCV2.1CTA110 Ultra Low Energy dMEV/Continuously running fan with Greenwood CommissionSMART™ technology and optional SMART Humidity and Timer options set-up at installation (For use with semi-rigid ducting only) IPX4 Ceiling 220–240VSelect 100 - Axial Flow Bathroom FanUnity CV2.1 is a continuously running extract fan, designed to offer a simplistic approach to meet Building Regulations and provide an energy efficient domestic ventilation solution to improve indoor air quality.• Extension to the industry leading Unity range of extract fans• Suitable for all installation applications Unity CV2.1 can be applied to all wet rooms and removes the need for large ducting networks and high background ventilation requirements • Once calibrated, the controls can be locked to avoid unnecessary changes being made to the fan’s running mode. Unity CV2.1 will also remember it’s calibrated settings in the event of loss of power, such as a power cut or during any maintenance to the property or the unit • Like other units in the Unity range, Unity CV2.1 can be installed in walls, windows (with a separate adaptor kit) or ceiling mounted and ducted quickly and easily, with minimal disturbances to existing infrastructure • Using as little as 0.5 Watts, Unity CV2.1’s energy performance is ideal for directly reducing carbon emissions in SAP • Unity CV2.1 short 68mm spigot design makes it perfect for application in shallow ceiling voids• The unique 100% variable airflow feature, conveniently achieved using the + and - buttons, offers peace of mind to Installers that Building Regulation compliance can be easily achieved• Unity’s SMART technology features, including automatic humidity sensing and a logical approach to overrun timing, help to reduce heat loss and energy wastage • Refined and sleek design helps Unity CV2.1 to blend in with its environment • The capacitive touch pad ensures ease of access, located on the front panel and simple commissioning • Unity CV2.1 offers ultra-quiet ventilation as low as 11dB(A) in low-speed mode once installedPart No. Description Voltage IP m3/h l/s Watts dB(A)*AXS100 Single speed 230 X4 72 20 13.2 33AXS100PC Single speed with pullcord 230 X4 72 20 13.2 33AXS100T Single speed with overrun timer & pullcord 230 X4 72 20 13.6 33AXS100TR Single speed with overrun timer & remote operation 230 X4 72 20 13.6 33AXS100HT Single speed with humidistat/timer & pullcord 230 X4 72 20 16.8 33AXS100SVIT Single speed SELV with overrun timer & pullcord 12 X7 72 20 17.8 33AXS100SVIHT Single speed SELV with humidistat/timer & pullcord 12 X7 72 20 17.2 33• Classic Ø 118 axial flow fan that complies with current Building Regulations – widely specified in new houses• Ø 100mm axial flow fans suitable for wall application. Ceiling mounting with discharge via external wall or soffit incorporating one 90° bend. Not suitable for vertical duct installations via a roof tile vent or similar• Wide range of control options including SELV (Safety Extra Low Voltage) for additional safety protection in wet rooms• Built in guide vanes to improve installed airflow performance • Includes anti-backdraught shutters to help reduce heat loss when not in operation• Clever spigot strengthener design helps to prevent crushing when attaching flexible ducting• Axial impellor design has flat surfaces that do not clog easily reducing the impact any dirt or other airborne particles have on fan performance
